Automatic Belting Waste Paper Baler With 6–8.4 T/H Capacity ,1000×1100mm Bale Size And Horizontal Structure
Automatic Belting Waste Paper Baler With 6–8.4 T/H Capacity ,
1000×1100mm Bale Size And Horizontal Structure
Product Introduction
The Waste Paper Baler features a horizontal structure with a 1250kN press force, equipped with PLC automatic control and automatic belting system. It is specifically designed for waste paper, cardboard, and carton recycling, offering stable operation, high bale density, and reduced transportation costs.
Applications
This Waste Paper Baler is widely used in:
-
Waste paper recycling stations
-
Paper mills
-
Logistics and sorting centers
-
Renewable resource recycling plants
Suitable for cardboard, corrugated paper, and mixed waste paper.
Technical Specifications
| Item | Parameter |
|---|---|
| Press Force | 1250 kN |
| Feeding Opening | 2200 × 1100 mm |
| Compress Box Size | 1800 × 1100 × 1100 mm |
| Bale Size | 1000 × 1100 mm |
| Bale Weight | 700–1150 kg |
| Bale Density | ≥400 kg/m³ |
| Capacity | 6.0–8.4 tons/hour |
| Power | 22 + 30 + 7.5 kW |
| Operation | Hydraulic + PLC Control |
| Belting | Fully Automatic, 5 Wires |
Key Advantages
-
High automation with automatic baling and belting
-
High-density bales reduce transport costs
-
Safe and reliable PLC-controlled operation
-
Flexible feeding options (manual or conveyor)
-
Manufactured under ISO9001 quality standards
After-Sales Service
-
1-year warranty and lifetime technical support
-
Installation guidance and operator training
-
Fast-response service from experienced engineers
![]()
