Through Hole X2 Safety Capacitor 2.5 Times Surge Voltage 1600VAC Dielectric Strength 50/60Hz
Product Description:
One of the key features of this product is its rated surge voltage of 2.5 times the rated voltage. This means that it can handle sudden voltage spikes without causing damage to the device it is protecting. This makes it an ideal choice for applications where voltage spikes are common.
The X2 Safety Device Capacitor has an operating temperature range of -40°C to +85°C, which means it can operate in a wide range of environments. This makes it an ideal choice for applications where temperature fluctuations are common, such as in automotive or industrial settings.
This product has a rated frequency of 50/60Hz, which means it can be used in electronic devices that operate at either of these frequencies. This makes it an ideal choice for a wide range of applications, from household appliances to industrial equipment.
Another important feature of the X2 Safety Device Capacitor is its insulation resistance of ≥ 10,000MΩ. This means that it can withstand high voltages without allowing current to flow through it. This is essential for protecting electronic devices from damage caused by high voltages.
The X2 Safety Device Capacitor is designed for through-hole mounting, which makes it easy to install in a wide range of electronic devices. This makes it an ideal choice for manufacturers who need a reliable and easy-to-install component for their products.
In conclusion, the X2 Safety Device Capacitor is an essential component for many electronic devices. Its high surge voltage rating, wide operating temperature range, and high insulation resistance make it an ideal choice for a wide range of applications. And with its through-hole mounting design, it is easy to install in a variety of electronic devices. So if you need a reliable and high-quality capacitor for your electronic device, the X2 Safety Device Capacitor is the perfect choice.
Features:
- Product Name: X2 Safety Protection Capacitor
- Rated Voltage: 250VAC
- Capacitance Range: 0.001uF - 4.7uF
- Rated Frequency: 50/60Hz
- Dissipation Factor: ≤ 0.1%
- Mounting Type: Through-Hole
Technical Parameters:
| Product Name | X2 Protective Device Capacitor |
| Product Type | X2 Safety Capacitor |
| Factory | X2 Safety Capacitor factory |
| Operating Temperature Range | -40°C To +85°C |
| Lead Wire Length | 15mm |
| Mounting Type | Through-Hole |
| Rated Surge Voltage | 2.5 Times Of Rated Voltage |
| Lead Wire Material | Tinned Copper |
| Capacitance Range | 0.001uF - 4.7uF |
| Insulation Resistance | ≥ 10,000MΩ |
| Size | P10 15 22.5 7.5MM |
| Rated Frequency | 50/60Hz |
| Package Type | Radial |
Applications:
Customization:
Support and Services:
The X2 Safety Capacitor is a highly reliable and durable product that is designed to meet the safety requirements of today's electronic devices. This capacitor is used in a wide range of applications, including lighting fixtures, power supplies, and home appliances. The product's technical support team is available to assist with any questions or issues that customers may have regarding the X2 Safety Capacitor. The team can provide guidance on installation, troubleshooting, and maintenance to ensure that the product performs at its best. In addition, the product comes with a comprehensive warranty and repair service to ensure that customers are fully satisfied with their purchase.
Packing and Shipping:
Product Packaging:
The X2 Safety Capacitor is packaged in a sturdy cardboard box to ensure safe transport and delivery. The product is neatly arranged inside the box with protective foam inserts to prevent any damage during shipping.
Shipping:
The X2 Safety Capacitor will be shipped via standard ground shipping unless expedited shipping is requested. Shipping costs will vary depending on the destination and shipping option selected.
FAQ:
Q: What is the brand name of this safety capacitor?
A: The brand name of this safety capacitor is CL.
Q: Where is this safety capacitor manufactured?
A: This safety capacitor is manufactured in China.
Q: What is the voltage rating of this safety capacitor?
A: The voltage rating of this safety capacitor is 250VAC.
Q: What is the capacitance value of this safety capacitor?
A: The capacitance value of this safety capacitor is 0.22μF.
Q: What is the size of this safety capacitor?
A: The size of this safety capacitor is 10mm x 18mm.
Product features and application circuit diagram
5.1
This product is made of polypropylene organic film as medium, surface metallized spray as electrode, and is made by winding. The exterior is made of flame-retardant plastic box body and potting with high temperature epoxy resin. Widely used in power supply crossover, inhibit the electromagnetic interference of the power supply, can not be used in the resistance-capacitance buck line, if you need the resistance-capacitance buck product, our company also has gray dedicated to the resistance-capacitance buck line.
5.2 Reference Standards
GB/T2693-2001 "Fixed capacitors for electronic equipment - Part I: General specification".
GB/T6346.14-2015 "Fixed capacitor for suppressing electromagnetic interference of power supply".
Iec 60384-14:2016.
GB/T2828.1-2003.
And safety certification related national standards and international standards
