China 17mm Unequal Angle Bar Yellow Reaction Towers 317L Angle Bar Iron for sale

17mm Unequal Angle Bar Yellow Reaction Towers 317L Angle Bar Iron

Price Negotiable

Price: bargaining

MOQ: 100kg. We also can accept sample order.

Delivery Time: Within 15-30 workdays after receiving deposit or L/C

Brand: Chengjiu

Product Description

17mm Unequal Angle Bar Yellow Reaction Towers 317L Angle Bar Iron

What are the two types of angle iron?

Usually, when looking for steel angles, customers will ask for “angle iron”, which we refer to as Hot Rolled (HR) Steel Angle. Within this category, there are two main types: bar size and L shapes.

2.Chemical composition and mechanical

Chemical composition
Material	C	Si	Mn	Cr	Ni	S	P	N
304	≤0.08	≤1.00	≤2.00	≤18.0-20.0	≤8.0-10.5	≤0.030	≤0.035	≤0.1

Mechanical properties of 304 stainless steel Angle steel

Mechanical properties of 304 stainless steel Angle steel yield strength (N/ MUM2)≥205

Mechanical properties of 304 stainless steel Angle steel tensile strength ≥520

304 stainless steel Angle steel mechanical properties elongation (%) ≥40

Angle steel mechanical properties of 304 stainless steel hardness HB≤187 HRB≤90 HV ≤200

Stainless steel Angle steel specification list

Angle of the side	thickness (mm)
A×Bmm	4	5	6	7	8	9	10
20×20	0.894	1.13	1.38
25×25	1.13	1.45	1.77	2.06
30×30	1.37	1.77	2.17	2.53
35×35	1.61	2.09	2.57	3.01
40×40	1.85	2.41	2.97	3.49
45×45	2.12	2.76	3.4	4
50×50	2.36	3.07	3.79	4.46	5.13	5.76	6.42
60×60			4.58	5.42	6.24	7.03
63×63			5.03	5.95	6.84	7.71	8.6
70×70			5.42	6.42	7.39	8.34	9.31
75×75			5.82	6.89	7.95	8.97	10
80×80				7.37	8.5	9.61	10.7
90×90				8.33	9.65	11.9	12.2
100×100				9.28	10.8	12.2	13.6
