L505 3KW Motor Power Aluminium Saw Cutting Machines For Window Door Corner
aluminium saw cutting machines
Features:
1, automatic CNC aluminum cutting machine has the characteristics of compact structure, simple operation, easy to operate and maintain;
2. The use of advanced cutting technology, can greatly improve production efficiency, reduce production costs;
3. High cutting precision, smooth cutting surface, can effectively ensure cutting quality;
4. Can be applied to different specifications of metal materials, can meet different processing needs;
5. Can carry out high speed, high efficiency, high precision cutting operation, greatly improve the production efficiency.
Advantages:
1. Automatic CNC aluminum cutting machine has the advantages of high precision, high efficiency and high automation;
2. Can carry out a variety of cutting methods, suitable for different processing needs;
3. Can carry out a large number of continuous cutting operations, suitable for mass production;
4. High cutting precision, smooth cutting surface, can effectively ensure cutting quality;
5. Simple operation, easy to operate and maintain.
Application:
Automatic CNC aluminum cutting machine is suitable for metal processing industry, mainly used for aluminum, copper and other metal materials cutting. In aluminum doors and Windows, electronics, metallurgy, automobile manufacturing and other industries have a wide range of applications. It can achieve high precision, high efficiency, high automation of cutting operations, greatly improve the production efficiency and production quality, is a very practical metal cutting equipment.
L505 3KW Motor power aluminium saw cutting machines for window door corner
Specification:
| Model | L405HQ | L505HQ |
| Performance | Specification | Specification |
| Sawing and cutting angle | 45°& 90° | 45°& 90° |
| Maximum sawing width(mm) | 400 | 500 |
| Maximum sawing height(mm) | 125 | 160 |
| Spindle speed | 2800-3300RPM | 2800-3300RPM |
| Install the largest saw blade | Φ405 | Φ505 |
| Motor power | 3KW | 4KW |
| Required pressure | 0.6-0.8MPa | 0.6-0.8MPa |
| Working table size(mm) | 530*830 | 580*830 |
| Size of packing box | 1350*1000*1480MM | 1350*1000*1480MM |
| Weight of machine | 400KG | 550KG |
| Size of material rack(Optional accessories) | Front 1000*390MM Back 150*390MM | Front 1000*390MM Back 150*390MM |
Detail:
Sample:
Features
1.Installation of hidden alloy saw blade, high safety performance.
2.The automatic injection section without edges, on both sides, the saw blade is more durable.
Automatic control pressure, cutting speed can be adjusted.
3.Fast pneumatic clamping and hydraulic feed, greatly improve the cutting stability.
4.Can be customized credle, before positioning , can be a plurality of sawing, cutting special materials.
5.Aluminum scrap concentrated recovery.
6.Suitable for all kinds of large size of the posterior wall of copper, aluminum and sheet metal cutting.
Zhangjiagang Liye Machinery Co., Ltd. (hereinafter referred to as the “Company”) is specialized in manufacture of machining equipment for metal pipes. The Company covers an area of more than 10,000 m2 with total assets of over CNY 20 million. The main products include 9 series and over 100 models, i.e. pipe machining line, pipe cutter, pipe bender, pipe end forming machine, chamfering machine, gear grinding machine, riveting machine, arc machine and bending press.
Our company is an entity factory.The company has a mature team about production, product research and development, and product inspection.Our products update faster .We can design or improve new type of machine to meet different customer needs.
