Full Automatic Solar Panel Support Roll Forming Machine Hardening Treatment Roller Material
Full Automatic Solar Panel Support Roll Forming Machine Hardening Treatment Roller Material
1. Profile drawing of solar panel support roll forming machine
2. Workflow of solar panel support roll forming machine
3. Main features of solar panel support roll forming machine
The advantages of solar panel support roll forming machine AUTOMATIC size-change type are as follows:
1.Produce different purlin size without changing rollers or spacers.
2.No need changing cutter for different size.
3.Easy operation, low maintenance cost
4.Infinite sizing(any size within machine range),help to save material
5.Optional Punch hole at any position of purlin web side and flange side
4.Supplying components of complete machine
| NO. | Description | Quantity (set) | Remark |
| 1 | Manual Decoiler 3 Ton | 1 | |
| 2 | Guiding device | 1 | One complete unit as main machine |
| 3 | Forming system | 1 | |
| 4 | Transmission system | 1 | |
| 5 | Flying Saw Cut | 1 | |
| 6 | Support table | 2 | |
| 7 | Hydraulic station | 1 | |
| 8 | Control box | 1 | |
| 9 | Spare parts and tools | 1 | As attaching list |
| 10 | Servo motor punching machine | 1 |
4. Detailed Images of solar panel support roll forming machine
|
Machine Specifications |
|
|
Weight |
About 12 tons |
|
Size |
About 15*1.2*1.2m(length x width x height) |
|
Color |
Main color: blue or as your requirement |
|
Warning color: yellow |
|
|
Suitable Raw Material |
|
|
Material |
Galvanized Steel Coils |
|
Thickness |
2.0 mm |
|
Yield Strength |
235Mpa |
|
Main Technical Parameters |
|
|
Quantity of forming rollers stations |
18 |
|
Diameter of forming rollers shafts |
80mm |
|
Roll Forming Speed |
15-25m/min |
|
Forming rollers material |
No.45 steel, coated with chromed treatment |
|
Cutter material |
Cr12MoV steel, with quenched treatment |
|
Controlling system |
PLC and Converter |
|
Electric Power requirement |
Main motor power: 22kw hydraulic motor |
|
Electric voltage |
According to customer’s requirement |
The CZ purlin which was produced by CZ purlin roll forming machine can be used for the major stress structure of the large and middle-sized industrial constructions and civilian constructions. The roof load bearing and wall panel supporting the plants, warehouses, engine houses, hangars, exhibition halls, cinemas, gymnasiums, fair flower stands, etc.
7. Our service
A. Foreign debugging
If you need, we will arrange our professional engineers to help you install and debug the machines well. Buyer should pay $60 per day
B. Guarantee period
The warranty will be maintenance, maintain in the guarantee period of 18 months starting from delivery. Because of the quality of equipment during guarantee period, we will provide the parts free of charges, which is in the conditions of correct operation. (Natural disasters or factors which can’t forced by human are excluded).
C. Training
During installation and adjustment of the equipment, our engineers shall provide the training to
buyer’s personnel request to operate and maintain the equipment. Including foundation construction, electrical works, hydraulic oil, safe operation and non-standard safety items, testing material and etc.
D. Lifetime services
Life time services to every customer.
