Solar PV Lithium Battery Electric Vehicle Lifepo4 24V 100Ah Battery
Lifepo4 24V 100Ah Energy Storage Battery Electric Vehicle Solar PV Lithium Battery
| Cell & Method | Lifepo4 |
| Dimension(L*W*H) | 328mm x 172mm x 220mm |
| Weight | Around 17.5KG |
| Rated Capacity | 100Ah |
| Min Capacity | 100Ah |
| High Rate Discharge Capacity | ＞ 90% Rated Capacity |
| Discharge Capacity @ -20℃(-4℉) | ＞ 70% Rated Capacity |
| Norminal Voltage | 24V |
| Energy | 2400Wh |
| Internal Impedance(@ 1000Hz.) | ≤20 mΩ |
| Cycle Life | ＞2500 Cycles @ 1C 100% DOD |
| Months Self Discharge | ≤ 5% @ 25℃(77℉) |
| Efficiency of Charge | 100% @ 1/3C |
| Efficiency of Disharge | 95% @1C |
| Max Charge Voltage | 28V |
| Charge Current | 1/2C, 20A |
| Max Charge Current | 100A |
| Standard discharge Current | 1C, 100A |
| Max Discharge Current | 3C, 120A |
| Discharge Cut-off Voltage | 24V |
| Charge Temperature | 0 ℃ to 45℃(32℉ to 113℉) @ 65±20%Relative Humidity |
| Discharge Temperature | -20℃ to 60℃(-4℉ to 140℉) @ 65±20%Relative Humidity |
| Storage Temperature | ≤ 1 Month, -20℃ to 60℃(-4℉ to 140℉) @ 65±20%Relative Humidity |
| ≤ 6 Month, -20℃ to 30℃(-4℉ to 80℉) @ 65±20%Relative Humidity |
FAQ
Q: Are u manfucture?
A: Yes, we are manufacturer in China,welcome you to visit our factory!
Q : When can I get quotation?
A : We usually quote within 24 hours after we get your inquiry.
Q : Can I get a lower price if I order large quantities?
A : Yes, cheaper prices with more bigger quantity orders.
Q2. How about your delivery time?
A: Usaully it take 1-2 weeks after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q4.what is your warranty?
We offer 5 years warranty for all our battery pack.we ensure at least 5000 cycle life for the LiFePO4 battery pack
