GMP Large Industrial Milk Spray Dryer Machine For Milk Instant Coffee Juice Powder
Description: Large Industrial Spray Dryer
2022 New Design Large Industrial Spray Dryer For Milk , Instant Coffee, Juice Powders, Additives Drying
the 3-stage purifying device. After the filtering, the air meets the 100000-grade standard. There are cooling devices for the
reactor, the temperature of the container wall is less than 80℃, and even the raw products are stayed on the wall, will not be burned. The powder rate is as high as more than 95%, and there is no powders mixing or wall hanging.
Features:
3.With the flushing device, the machine can be applied for the drying for many kinds of products.
4.The wet-type dust collecting is adopted, which meets the environment protecting standard.
5.There is the air cleaning device.
8.CIP
Technical Parameters
|
Model
|
GLP5
|
GLP25
|
GLP50GLP
|
100
|
GLP150 |
GLP200
|
|
Inlet temperature
|
140°C-350°C
Adjustable |
140°C-350°C
Adjustable |
140°C-350°C
Adjustable |
140°C-350°C
Adjustable |
140°C-350°C
Adjustable |
140°C-350°C
Adjustable |
|
Outlet temperautre
|
80°C -90°C
|
80°C -90°C
|
80°C -90°C
|
80°C -90°C
|
80°C -90°C
|
80°C -90°C
|
|
Maximum water evaporation
|
5kg/h
|
25kg/h
|
50kg/h
|
100kg/h
|
150kg/h
|
200kg/h
|
|
Maximum speed (r.m.p)
|
25000
|
22000
|
21500
|
18000
|
18000
|
16000
|
|
Heating rouse
|
Electric
|
Steam+Electric
|
Steam+Electric/gasoline/coal gas/hot-blast stove
|
|||
|
Heating power
|
8KW
|
31.5KW
|
60KW
|
81KW
|
99KW
|
---
|
|
Dimension
|
1.6*1.1*1.75m
|
4*2.7*4.5m
|
4.5*2.8*5.5m
|
5.5*4*7m
|
7*5.5*7.2m
|
7.5*6*8m
|
|
Lifting height of nozzle
|
-----
|
2.5m
|
2.5m
|
3.2m
|
3.2m
|
3.2m
|
|
Dry powder recovery rate
|
≥95% |
≥95% |
≥95% |
≥95% |
≥95% |
≥95% |
Our Factory
SNYNXN is specialized in design, development, manufacture and sale of pharmaceutical, food, chemical extracting and drying equipments for more than 20 years. Our products include Dryer, Granulator, Mixer, Crusher, Evaporator and distiller etc.
Looking to the future with a commitment to design innovation and quality products, supported by an outstanding level of customer service. The unexcelled quality medical machinery can be easily obtained from us because we maintain the quality and standard of our products from incoming raw materials to the finished products.
Our company follows strict quality controls and various systematic procedures. We take utmost care of quality at every stage of the manufacturing process. Our research and development wing is our asset that develops and incorporates innovative ideas and products.
Our Team is full of experienced and qualified professionals, who have sound knowledge about the quality of our medical machinery. Our products are far sold to Europe, U.S.A., and the southeast Asia. They are well received by customers both at home and abroad.
Q: What information should be provided in order to get a proposal or quotation?
A: Our spray dryer can be customerized. Before we can work out a detailed quotation, we have to know the following information:
1) What liquid material are you going to dry? Moisture type and viscosity ?
2) Moisture content before drying? Target moisture content of dried powder?
3) Required powder size distribution ?
4) Your recommended drying temperature?
5) Heat souce? Steam or electricity
6) Construction material ? SS304/SS316L
Q: How the dryer will be delivered ?
A: The dryer is packed in plywood box for shipping
Q: Do you provide free drying test?
A: Yes. We have pilot plant for free drying test.
