50L To 500L Hemp Oil Industrial Extraction Equipment Cbd Essential Oil Extraction Machine
Price:
Negotiable
MOQ:
1
Delivery Time:
Within 50 Days After Order
Brand:
SNYNXN
Product Description
Description of Multi-Functional Extraction Machine Essential Oil Extractor
Usage: This machine is our company new developed extractor and concentrator machine, it is developed based on the thermal reflux extractor and concentrator machine, it ismuch fit to the medicine company extractor process. Machine composite: This machine including the following units: extractor tank, single effect concentrator, condenser, automatic water drain system,oil/water separater, filter, sanitary pump and pipeline.
Machine operation mode: Manual operation & automatic operation.
Main Technical Data
|
Model
|
NST-1.0
|
NST-2.0
|
NST-3.0
|
NST-4.0
|
||||
|
Extractor tank
|
Concentrator
|
Extractor tank
|
Concentrator
|
Extractor tank
|
Concentrator
|
Extractor tank
|
Concentrator
|
|
|
Jacket pressure(Mpa)
|
0.3
|
0.2
|
0.3
|
0.2
|
0.3
|
0.2
|
0.3
|
0.2
|
|
Inside pressure(Mpa)
|
≤0.09
|
-0.084
|
≤0.09
|
-0.084
|
≤0.09
|
-0.084
|
≤0.09
|
-0.084
|
|
Jacket temp(℃)
|
142
|
132
|
142
|
132
|
142
|
132
|
142
|
132
|
|
Inside temp(℃)
|
≤100
|
60
|
≤100
|
60
|
≤100
|
60
|
≤100
|
60
|
|
Evaporate capacity(kg/h)
|
500
|
800
|
1000
|
2000
|
||||
|
Dimension(L*W*H)
|
4000*1800*4400
|
4500*2200*4800
|
5200*2400*6000
|
6600*2800*7000
|
||||
Features:
1.This machine can be used as atmospheric pressure extractor, atmospheric pressureconcentrator for the solvent based thermal reflux extractor process, also can be used atmospheric pressure extractor, vacuum low temperature concentrator process for themulti-times water based extractor process. so this machine resolve the problem of thetemperature -sensitive medicine easy destroyed on the high temperature.
![]()
![]()
2.This machine can load much more raw material compare with the common extractor tankand also can save the solvent solution consumption, low evaporate temperature and energysaving.
3.This machine have the automatic water drain system, it will save the labour and machine safety.
Q: Are you manufacturer or trading company?
A: SNYNXN is a professional manufacturer, we have more than 15years experience in pharmaceutical machine field.
Q: Where is your factory located?
A: We are located in Jiangyin City, Jiangsu China. 1 hour by car to Shanghai, 2 hour fly to Guangzhou. welcome to visit our factory.
Q: what is your business scope?
A: Active pharmaceutical ingredients, Herbal extracts, Western Medicine, Beverage, Dairy and Food.
Q: How could we confirm the details of the products?
A: Drawings will be provided for you to confirm.
Q: Will you change us for drafting if we have specail requests?
A: No, we will not. Free of charge to make a draft or offer. ODM
Q: How long the warranty will be?
A: 1 year warranty. 2Years for core componets.
Q: How about the installation? And what if the machine goes down.
A: Yes, we will do that. There are two options: a. We could appoint our engineer to your company to debug and repair, as for the cost of this trip such as ticket, visa, accommodation and labor cost shall be on your side. b. On-line service will be provided. If still under guarantee period, the necessary accessories and parts will be provided free, but the transportation cost of it shall be on you side.
Q: Do you take L/C?
A: Yes, we accept Western Union, T/T and irrevocable L/C payable
Q: Can we become your distributor in our country?
A: Yes, we very welcome you! More details will be discussed if you are interested in being our agent.
