Grayscale Bright LED Screen Modules Rental Waterproof 1R1G1B
TENBULL P4.81 P3.91 P2.064 P1.875 1R1G1B led screen rental creative waterproof led display
Quick detail
1.Pixel pitch:4.81mm
2.Pixel configuration:full color 1R1G1B
3.Module weight 1.2kg
4.cabinet size:500mm*1000mm
5.MTBF:≥9000hours
Product detail
1.Its gray scale display is uniform and consistent, with high contrast and non reflective surface.
2.The picture is clear and natural, without flicker, delay or mosaic; And it changes the picture more quickly, and the color display is more symmetrical.
3.Adopt a high-quality blanking solution: completely eliminate the phenomenon of ghosting, dark and bright, and the viewing effect is good.
4.Applications: Suitable for military and public safety, energy, urban management, public information release platform, transportation and transportation, radio and television, cinema, enterprise video conference system, medical, education and other fields of fixed installation occasions.
5High-quality LED wafers are selected, with large angle, good flatness, low antistatic brightness attenuation and high wavelength stability.
6.This product adopts non-linear point by point correction technology, so that the display effect is better, the text is clearer, and the sense of hierarchy is stronger.
P4.81 PARAMETER
| MODULE | Iterm | parameter |
| Product model | P4.81-13S | |
| Module size | 250mm*250mm | |
| Pixel pitch | 4.81mm | |
| Pixel density | 43264dot/m2 | |
| Pixel configuration | 1R1G1B | |
| LED type | SMD1921 | |
| IC | FM6353 | |
| Pixel resolution | 52dots(W)*52dots(H) | |
| Max Power consumpion | 60W | |
| Module weight | 1.2kg | |
| Drive type | Constant drive | |
| Scan mode | 1/13 scan | |
| LED cabinet | cabinet size | 500mm*1000mm |
| Module quantity | 8pcs | |
| Power supply | 5V/60A | |
| Pixel per cabinet | 104*208 | |
| Brightness of white balance | ≥5000cd/m2 | |
| Best viewing distance | 4M～50M | |
| The best perspective | 160°(W) 120°(H) | |
| Temperature | storage:-35℃～+85℃ work:-20℃～+50℃ | |
| Opration humidity | 10%-95% | |
| Thickness | 85mm | |
power
| Working voltage | AC220V±10% |
| Average Power | 400W/S | |
| Max.Power consumption | ≤800W/S | |
| Current | ≤20mA(single LED) | |
Control syste
| CPU | Pentium4 or above |
| Operation system | WIN98/2000/NT/XP | |
| Control method | Synchronization | |
Main technical parameter | Driving device | Constant currentdriver IC |
| Refresh frequency | ≥3840HZ | |
| Grey scale/colors | 256levels of each color(RGB)/16.7M colors | |
| MTBF | ≥9000hours | |
| Power switch | Automatic switch | |
| Display Mode | 800*600/1024*768 |
Product photo
FAQ
Q1.What pixel pitch should I choose on my display?
A:It is determined mainly by the viewing distance, the size of the display screen, the desired effect and the customer budget.
Q2.Can I order a sample?
A:Yes,We welcome customers to order samples to check our product quality of our products and service.
Q3.What about your quality?
A:The quality of our display is excellent. We use the materials of high quality suppliers in the world,strictly control the production process, and pass the multiple quality inspection to ensure that every product is qualified.
