Din Rail Industrial Gigabit PoE Switch 2 SFP Aluminum Alloy Shell SR-SHG2210FPI
Price:
Negotiation
MOQ:
20
Delivery Time:
5-8 work days
Brand:
Sirivision
Product Description
Industrial Poe Switch Gigabit 8 Electric Ports And 2 SFP Fiber Ports, Aluminum Alloy Shell SR-SHG2210FPI
Industrial Easy Smart Gigabit PoE Switch With 2G SFP Slots And 8GE Ports
Description Of The Industrial Ethernet Switch:
The SR-SHG2210FPI is an industrial grade PoE switch with 8 Gigabit Ethernet auto-sensing electrical ports and 2 Gigabit SFP fiber ports, MTBF up to 10 years, 3 years warranty, and excellent adaptability to industrial field environment (including mechanical stability, climate environment adaptability, electromagnetic environment adaptability, etc.). It supports IEEE802.3, IEEE802.3i, IEEE802.3u, IEEE802.3x, IEEE802.3z, IEEE802.3ab, IEEE802.3af, IEEE802.3at. protocol standards and complies with CE, ROHS, FCC, UKCA.
Features Of The Switch Industrial:
- Provide 8 10/100/1000Mbps RJ45 ports, 2 10/100/1000Mbps SFP fiber ports.
- Support IEEE 802.3, 802.3i, 802.3u, 802.3x, 802.3z, 802.3ab, 802.3af, 802.3at.
- 8 PoE ports support 802.3af/at, per port up to 30W Poe power budget.
- IP30 protection can reduce the impact of dust.
- EMC high protection level, no fear of various harsh environments.
- Support port security control, broadcast storm suppression and other functions.
Product Spectification Of The Industrial Poe Switch:
| SR-SHG2210FPI | |
| Power Supply | 44~ 57 V DC/ 3A(MAX) |
| Standards | IEEE 802.3, 802.3i, 802.3u, 802.3x, 802.3z, 802.3ab, 802.3af, 802.3at |
| Ports | 8×10/100/1000Mbps RJ45 PoE ports +2×SFP ports |
| Indicators | 8 status indicators Link/ACT, 8 PoE indicators, 2 SFP fiber port indicators (Link), power indicator |
| Forwarding Mode | Store and Forward(Full Wire Speed) |
| Dimensions | 149.2 mm *122 mm *50 mm |
| PoE port | 8 802.3at/af standard POE |
| Max / Average Power Port | 30W per port |
| MAC Address Table | 4K |
| Switching Capacity | 20Gbps |
| Packet Forwarding Rate | 14.88Mpps |
| Installation | DIN rail/wall mount |
| Environment | Operating Temperature: -40℃ — 75℃ (-40℉~167℉) Storage Temperature:-40℃ — 85℃ (-40℉ ~185℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| Certification Standards_ EMS |
IEC/EN 61000-4-2,Level 4 IEC/EN 61000-4-3,Level 4 IEC/EN 61000-4-4,Level 4 IEC/EN 61000-4-5,Level 3 IEC/EN 61000-4-6,Level 3 IEC/EN 61000-4-8,Level 5 IEC/EN 61000-4-9,Level 5 IEC/EN 61000-4-10,Level 5 |
Soft Features:
| L2 Switching Features | • IGMP Snooping - Supports IGMP Snooping - Supports 128 groups |
| • Link Aggregation - Supports static link aggregation - Supports 8 groups of aggregation, up to 4 ports per group |
|
| • Port Mirroring - One-to-one - Many-to-Many |
|
| • Support port isolation, port grouping | |
| VLAN | • Supports up to 32 VLANs (out of 4K VLAN IDs) |
| • Supports Port VLAN and 802.1Q VLAN | |
| • Supports Port-based/802.1p/DSCP priority | |
| Quality of Service (QoS) |
• Support 4 priority queues |
| • Port Speed Limit | |
| • Storm Control | |
| Management | • Support WEB network management, IP:192.168.1.199 User name and password is:admin |
| Ethernet Protocols | • IEEE 802.3 10BASE-T |
| • IEEE 802.3u 100BASE-TX/FX | |
| • IEEE 802.3ab 1000BASE-T | |
| • IEEE 802.3x Flow Control | |
| • IEEE 802.1q VLANs/VLAN tagging | |
| • IEEE 802.1p QoS |
Product Application Of The Industrial Network Switch:
