Water Filtration Continuous Filament Nonwoven Geotextile 1.7mm Short Fiber
Price:
0.25 USD ~3.8 USD per sqm
MOQ:
1100sqm
Delivery Time:
5~8 working days
Brand:
Wanshengli
Product Description
1.7mm Short Fiber Water Filtration Reinforce Geotextile Geosynthetic Fabric Product
Geosynthetic Fabric Short Non Woven Geotextile
Geotextiles are permeable nonwoven fabrics used to separate,filter,reinforce, protect or drain. Geotextiles allow filtration or separation of granular layers in roads and railway applications ,used to protect membranes in landfill applications,used in coastal defence applications and used in landscaping to protect surfaces and structures from weeds and root growth.
![]()
Geosynthetic Fabric Features
- Good flexibility
- Corrosion resistance
- Acid and alkali resisitance
- Oxidation resistance
- Good water permeability
- Filtration and isolation performance
Product Parameter
| No. |
Item Index Specification |
100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | 800 | Remarks |
| 1 | Unit area mass deviation,% | -8 | -8 | -8 | -8 | -7 | -7 | -7 | -7 | -6 | -6 | -6 | |
| 2 | thickness, mm ≥ | 0.9 | 1.3 | 1.7 | 2.1 | 2.4 | 2.7 | 3 | 3.3 | 3.6 | 4.1 | 5 | |
| 3 | Width deviation, % | -0.5 | |||||||||||
| 4 | Breaking strength, KN/M ≥ | 0.08 | 0.12 | 0.16 | 0.2 | 0.24 | 0.28 | 0.33 | 0.38 | 0.42 | 0.46 | 0.6 | Vertical and horizontal |
| 5 | Elongation at break, % | 25-100 | |||||||||||
| 6 | CBR bursting strength,KN ≥ | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | 2.7 | 3.2 | 4 | |
| 7 | Equivalent aperture,O99(O35),mm | 0.07-0.2 | |||||||||||
| 8 | Vertical permeability coefficient,cm/s | KX(10 -1 -10 -3 ) | K=1.0-9.9 | ||||||||||
| 9 | Tear strength 3,KN ≥ | 0.08 | 0.12 | 0.16 | 0.2 | 0.24 | 0.28 | 0.33 | 0.38 | 0.42 | 0.4 | 0.6 | Vertical and horizontal |
Applications
- As the isolation layer and for inverted layer dam, slope protection, road, railway, airfield runway.
- Reinforcement and drainage for soil slope,retaining wall.
- Reinforcement and drainage for Asphalt pavement, cement concrete pavement and subgrade enhancement. Both rigid and flexible road pavement applicable.
- Soft foundation treatment/ soft soil improvement of port project; the reinforcement and drainage for beach dike, seaport wharf and seawall/bulwark.
Geosynthetic Fabric Geotextile Package
packed as rolls with tight belt and woven bags. I t can gurantee onvenient unloading and protecting product.
