220V Single Phase Brushless 100W-750W BLDC Pump Motor For Commercial Heat Pump

220V Single Phase 100W-750W AC BLDC Motor For Commercial Heat Pump

Introduction

Changzhou Hengsheng Electric Co., Ltd, located in Changzhou city, Jiangsu Province, has been specialized in the field of exporting high quality AC BLDC motor for heat pump, air conditioning, heating and ventilation.This Single phase 100W-750W AC BLDC Motor for commercial heat pump is customized by customer for heat pump outdoor unit. We can also sell motors with fans as solution.

Quick Details

Output Power:100-300W

Type: AC BLDC Motor

Frequency:50/60hz

Phase:Single-phase/Three phase

Certification:CCC, CE, ROHS, UL

Protect Feature:Totally Enclosed

Rated Voltage:115/120 V/208-230V

Insulation:Class B/H

Features:

Reversible plug for easy rotation; Quick installation; Quiet operation;

Ball bearing; Dual voltage 115/208-230 v

Run capacitor pre-mounted on motor; Automatic overload; Operating temp -10-43 degree

High efficiency,High reliability,Little vibration,Low noise Thermal protection

Specification

More information

Structure of heat dissipation motor of air energy heat pump:

The heat dissipation motor of air energy heat pump is composed of stator, rotor and other accessories. The specific components of different types of air energy heat pump cooling AC/BLDC motors will be slightly different. Permanent magnet DC motor is composed of stator magnetic pole, rotor, brush, shell, etc. The stator magnetic pole is made of permanent magnet, ferrite, aluminum nickel cobalt, iron boron and other materials. BLDC motor is composed of permanent magnet rotor, multipole winding stator, position sensor, etc. Single phase asynchronous AC motor consists of stator, rotor, bearing, casing, end cover, etc. If you are interested in our AC BLDC motor, please feel free to send us the inquiry.
