750w AC BLDC Motor 800-3000rpm High Power 1HP DC EC Motor For Fan Blower Or Air Conditioner

High power 1HP 750w EC BLDC motor for fan blower or air conditioner

Introduction

This page shows a high power EC/BLDC fan motor used in fan blower or air conditioner units and similar applications, which need to drive fan blowers.

Till now, Hengsheng has a various of specifications of AC BLDC motors, and different induction motor, geared motor, PM motor with gearbox. Because of its long working life, stable performance and low failure rate, our products are well received by customers. We have got the certification of CCC, RoHS and ISO9001:2008.

Features of BLDC motor

1. Rated Voltage:200-240V 50Hz/60Hz

2. Output power range: 750W

3. Speed 300-1500 adjustable

4. The driver adopts the structure of aluminum shell completely closed, which has high protection level and is safe and reliable.

5. The driver adopts independent installation structure, which is convenient for disassembly and maintenance after sale.

6. The driver is integrated with three-speed, VSP10V,AC24V,PWM/PWF, RS485 control mode, and the function of speed feedback is optional.

7.Using infrared remote control, adjustable constant speed,constant torque, fan coil unit load, cassette fan coil unit load.clockwise or counterclockwise rotation

8.Using the same structure and installation method as the single-phase electric power, it is more convenient to replace and popularize

9.Rated speed 1070 RPM, rated output power 750W, Max Torque 6.5 Nm.

Specification

Application of Brushless DC Motor

Brushless DC motors are widely used in a variety of applications, such as industrial control, automotive, aviation, automation systems, medical care equipment and other fields in a variety of loads, constant loads and positioning applications. Household appliances

"Inverter" technology has become very popular. As the symbol of Chinese household appliances, it has gradually occupied most of the consumer market. "DC inverter" is favored by manufacturers, and has gradually replaced the "AC frequency conversion" trend. In essence, this transformation is the transition from induction motor to brushless DC motor and its controller, so as to meet the requirements of energy conservation, environmental protection, low noise, intelligence and high comfort. The development direction of brushless DC motor is the same as that of power electronics, sensors, control theory and other technologies. It is a combination of multiple technologies, and its development depends on the innovation and progress of each related technology.
