Lithium Powerwall Home Battery 10kw 20kwh 51.2V 100ah Wall Mounted Lifepo4

Name: Lithium Powerwall Home Battery 10kw 20kwh 51.2V 100ah Wall Mounted Lifepo4
Brand: guangzhou pmd technology co ltd

Price Negotiable

Price: negotiated

MOQ: negotiated

Delivery Time: negotiated

Product Description

Powerwall 20kwh Home Lithium Battery Solar Storage 10kw Powerwall Smart Bms 51.2v 100ah Wall Mounted Lifepo4

Product Description

Model No	48100	48200	51100	51140	51200
Batteries materials	Lithium iron phosphate
Nominal voltage	48V	48V	51.2V	51.2V	51.2V
Nominal capacity	100Ah	200Ah	100Ah	140Ah	200Ah
Size(mm)	471375147	590375245	67054090	1095420150	980700100
Weight	42kg	82kg	50kg	73kg	85kg
Color	Optional
Parallel support	Parallel terminals are supported
Output port mode	terminal
Charging way	CC/CP/VP
Charging current	0.2C(standard)
Maximum charging current	Max0.5C @25℃
Discharge way	CC/CP/VP
Discharge current	0.5C
Charge cut-off voltage	54.8V/CELL
Maximum discharge current	Max1.2C @25℃
Discharge cut-off voltage	36.4V	36.4V	44.8V	44.8V	44.8V
According to	LCD
Communication interface	RS485/RS232/CAN
Charging operating temperature	charging:0~+50℃
Discharge operating temperature	discharge:-20~+55℃
The quality assurance period	5 years
Applicable scope	hospital, bank data center, base frame type home,enterprise energy storagebackup power supply, wind complementary system,office, military, base station and other uninterrupted energy storage power supply.
