Wall Mounted Smart Energy Storage System For House 6kw 51.2v 106AH Energy Storage System With Solar Panels
Product parameters
Battery Type
Lithium Ion
Output Power Range
0-5 kWh
System Type
Stackable
Model Number
MHO-HV
Brand Name
PMD
Place of Origin
China
Dimension (L*W*H)
600*400*(685~1335)mm
Weight
178~408kg
Type
Split
Communication Port
CAN
Protection Class
IP65
Grid connection
Off grid, Hybrid grid
Product name
home use solar power energy storage system
Nominal Voltage (V)
153.6V204.8V256.0V307.2V358.4V409.6V
Nominal Capacity (Wh)
16.28KWH21.7KWH27.13KWH32.56KWH37.99KWh43.41KWH
Design Life
15+ Years (25°C/77F)
Weight(kg)
178/218/258/308/358/408
ELECTRICALCycle Life
>6000times (25°C)
Discharge Voltage range(V)
120-144/160-192/200-240/240-288/280-336/320-384
Charge Voltage range(V)
168-175.2/224-233.6/280-292/336-350.4/392-408.8/448-467.2
Charge/Discharge Current(A)
100A/60A (Recommended)100A(Max)
Internal Resistances
30mΩ
