350kg 500kg 800kg 1000kg 1500kg Double Scissor Hydraulic Electric Table Hydraulic Lift
350kg 500kg 800kg 1000kg 1500kg Double Scissor Hydraulic Electric Table Hydraulic Lift
Scissor lift tables are used in a variety of industrial, construction and manufacturing applications. They are ideal for lifting and positioning heavy loads in areas where space is limited and access is difficult. The table can be easily adjusted to the desired height, providing a safe and stable platform for the load.One of the key benefits of a scissor lift table is its versatility. It can be used for a wide range of tasks, from lifting and positioning heavy machinery, to transporting goods in a warehouse. The table can be fitted with a range of attachments, such as casters, conveyors, and workstations, to increase its functionality and make it more suitable for specific tasks.
- Load range: 1000kg~4000kg. Or customized according to customer requirements.
- Platform Size: standard parameters or special customization.
- Maximum lifting height: customized.
Standard Hysraulic Electric Scissor Lift Tbale Parameters:
(Can be customized if special size or requirement)
| Model | Load Capacity(KG) | Self Height(MM) | Max Platform Height(MM) | Platform Size(MM) | Base Size(MM) | Lifting time(s) | Motor(KW) | Net weight(KG) |
| SLT01 | 1000 | 205 | 1000 | 1300×820 | 1240×640 | 20~25 | 1.1 | 160 |
| SLT02 | 1000 | 205 | 1000 | 1600×1000 | 1240×640 | 20~25 | 1.1 | 186 |
| SLT03 | 1000 | 240 | 1300 | 1700×850 | 1580×640 | 30~35 | 1.1 | 200 |
| SLT04 | 1000 | 240 | 1300 | 1700×1000 | 1580×640 | 30~35 | 1.1 | 210 |
| SLT05 | 1000 | 240 | 1300 | 2000×850 | 1580×640 | 30~35 | 1.1 | 212 |
| SLT06 | 1000 | 240 | 1300 | 2000×1000 | 1580×640 | 30~35 | 1.1 | 223 |
| SLT07 | 1000 | 240 | 1300 | 1700×1500 | 1580×1320 | 30~35 | 1.1 | 365 |
| SLT08 | 1000 | 240 | 1300 | 2000×1700 | 1580×1320 | 30~35 | 1.1 | 430 |
| SLT2001 | 2000 | 230 | 1000 | 1300×850 | 1220×785 | 20~25 | 1.5 | 235 |
| SLT2002 | 2000 | 230 | 1050 | 1600×1000 | 1280×785 | 20~25 | 1.5 | 268 |
| SLT2003 | 2000 | 250 | 1300 | 1700×850 | 1600×785 | 25~35 | 2.2 | 289 |
| SLT2004 | 2000 | 250 | 1300 | 1700×1000 | 1600×785 | 25~35 | 2.2 | 300 |
| SLT2005 | 2000 | 250 | 1300 | 2000×850 | 1600×785 | 25~35 | 2.2 | 300 |
| SLT2006 | 2000 | 250 | 1300 | 2000×1000 | 1600×785 | 25~35 | 2.2 | 315 |
| SLT2007 | 2000 | 250 | 1400 | 1700×1500 | 1600×1435 | 25~35 | 2.2 | 415 |
| SLT2008 | 2000 | 250 | 1400 | 2000×1800 | 1600×1435 | 25~35 | 2.2 | 500 |
| SLT4001 | 4000 | 240 | 1050 | 1700×1200 | 1600×900 | 30~40 | 2.2 | 375 |
| SLT4002 | 4000 | 240 | 1050 | 2000×1200 | 1600×900 | 30~40 | 2.2 | 405 |
| SLT4003 | 4000 | 300 | 1400 | 2000×1000 | 1980×900 | 35~40 | 2.2 | 470 |
| SLT4004 | 4000 | 300 | 1400 | 2000×1200 | 1980×900 | 35~40 | 2.2 | 490 |
| SLT4005 | 4000 | 300 | 1400 | 2200×1000 | 2000×900 | 35~40 | 2.2 | 480 |
| SLT4006 | 4000 | 300 | 1400 | 2200×1200 | 2000×900 | 35~40 | 2.2 | 505 |
| SLT4007 | 4000 | 350 | 1300 | 1700×1500 | 1620×1400 | 35~40 | 2.2 | 570 |
| SLT4008 | 4000 | 350 | 1300 | 2200×1800 | 1620×1400 | 35~40 | 2.2 | 655 |
Description:
- To provide exceptional anti-corrosion protection, the surface of the Scissor Lift Table undergoes a high-quality stoving varnish treatment, ensuring long-lasting durability.
- The premium pump station guarantees smooth and stable lifting and lowering operations, ensuring reliable performance and user satisfaction.
- The scissor design incorporates advanced anti-pinch technology and self-lubricating main pin-rolls, enhancing the table's durability and reducing maintenance requirements.
- For easy lifting and installation, a removable lifting eye is included, simplifying the process and improving efficiency.
- The heavy-duty cylinders are equipped with a drainage system and check valve to prevent unexpected lowering in the event of a hose burst, prioritizing safety during operation.
- A pressure relief valve is integrated to safeguard against overloading, while the flow control valve allows for adjustable descent speed, providing precise control and versatility.
Safety Precautions:
- Industrial scissor lift table Explosion-Proof Valves: These valves safeguard the hydraulic pipes and prevent hydraulic pipe ruptures.
- Pressure Relief Valve: This valve helps regulate pressure and prevents high pressure buildup during upward movements.
- Emergency Descent Valve: In the event of an emergency or power failure, this valve enables a controlled descent of the platform.
- Anti-Fall Device: This feature ensures the stability and safety of the platform, preventing any accidental dropping.
- Automatic Safety Sensors: Equipped with sensors, the lift platform will automatically stop when it encounters any obstacles or barriers.
Conditions:
Quality warranty: 24 Months.Free Spare Parts Replacement.
Packing: will be packed by high quality boxes and put on pallet.
