EFC-25 Adjustable Electric Powered Floor Crane Load 1200kg For Workshop
Price:
USD 2000~USD 5000
MOQ:
1 set
Delivery Time:
15-25 work days
Brand:
HESHAN
Product Description
EFC-25 Adjustable Electric Powered Floor Crane Load 1200kg For Workshop
An Adjustable Electric Powered Floor Crane is a versatile and powerful lifting device designed to lift and move heavy loads with ease. This type of crane is typically floor-mounted and can be easily moved around the worksite using wheels or casters.
The Adjustable Electric Powered Floor Crane is operated using an electric motor that powers the lifting mechanism. It can be controlled using a wired or wireless remote control, allowing the operator to move the crane and lift the load from a safe distance.
One of the key features of this type of crane is its adjustable height and reach. This allows it to be used in a range of different settings and to lift loads from different angles. The adjustable height and reach also make it easier to maneuver the crane in tight spaces and narrow aisles.
The Electric Powered Floor Crane is typically equipped with different types of lifting attachments, such as hooks, slings, or magnets, to accommodate different types of loads. It can also be equipped with safety features such as overload protection and emergency stop buttons to ensure the safety of the operator and the load being lifted.
Specification:
| Model Type | EFC-25 | EFC-25-AA | EFC-CB-15 | ESC900R Electric rotation 240° |
| Drawing | On following Page 2 | On following Page 3 | On following Page 4 | On following Page 5 |
| ( Extended 2 stages) | 1280+610+610mm | 1280+610+610mm | 1220+610+610mm | 1280mm+610mm+610mm |
| Load Capacity | 1200kg | 1200kg(1280mm) | 700kg(1220mm) | 900kg(1280mm) |
| Load Capacity (stage 1) | 600kg(1280~1890mm) | 600kg(1280~1890mm) | 400kg(1220~1830mm) | 450kg(1280~1890mm) |
| Load Capacity (stage 2) | 300kg(1890~2500mm) | 300kg(1890~2500mm) | 200kg(1890~2440mm) | 250KG(1890~2500mm) |
| Max Lifting Height | 3570mm | 3540mm | 3560mm | 3180mm |
| Min Lifting Height | 960mm | 935mm | 950mm | 1410mm |
| Retracted size(W*L*H) | 1920*760*1600mm | 1865*1490*1570mm | 2595*760*1580mm | 2000*1854*1550mm |
| Arm Electric Rotation | / | / | / | 120°left/right |
