3.7V 1200mAh 14500 Lithium Ion Battery Cell More Than 500 Cycles
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
Tuorde
Product Description
3.7V 1200mAh 14500 cell,energy cell,more than 500 cycles
High capacity,High quality
Shenzhen Tuorde energy Co.,Ltd is a professional and reliable manufacturer in China.
| No. | Item | Specifications |
| 1 | Model No. | TRD14500-1200 |
| 2 | Typical Capacity | 1200mAh @0.2C Discharge |
| 3 | Nominal voltage | 3.7V |
| 4 | Standard Charge | CC/CV,0.2C,4.255V |
| 5 | Standard Discharge | CC,02C,2.5V |
| 6 | Cut-off charge Voltage | 4.255V |
| 7 | Cut-off charge Current | 0.02C(At CVmode) |
| 8 | Cut-off discharge Voltage | 2.5V |
| 9 | Charging Time | 8.0hours(standard charge) |
| 10 | Quick Charge Current | 600mA(0.5C) |
| 11 | Quick Discharge Current | 600mA(0.5C) |
| 12 | Max Discharge Current | 600mA(0.5C) |
| 13 | Initial Impedance | ≤40mΩ |
| 14 | Weight | Approx:20 g |
| 15 | Operating temperature | Charging:0℃~45℃ Discharging:-10℃~60℃ |
| 16 | Storage temperature | -10℃~45℃≤ one months |
| 17 | Storage Humidity | ≤75%RH |
| 18 | Standard environmental condition | Temperature:25±2℃ Humidity:45-75%RH Atmospheric Pressure:86-106KPA |
