Rock Fragmentation Jaw Rock Crusher Hard Iron Ore Crushing Plant Machine 15KW
Price:
USD 5,753.42-6,774.19 one set
MOQ:
1 set
Delivery Time:
20 days
Brand:
BENO
Product Description
Hard Rock Fragmentation Jaw Rock Crusher Light Crushing Equipemnt Stable Operation
Product Description
As a primary crushing equipment, the Jaw Rock Crusher can effectively process a large number of hard rocks, such as river pebbles, iron ore, granite, gold ore, limestone, etc. Jaw Rock Crusher is widely used in mining, smelting, highway, building materials and other fields.
The main components of the jaw crusher include frame, eccentric shaft, moving jaw body assembly, tooth plate, protective plate, adjustment seat, elbow plate, tie rod spring, pulley, motor, etc.
Equipment Advantages
1. The Jaw Rock Crusher can break all kinds of hard rock. Complete the coarse and fine breaking of different aggregates.
2. The Jaw Rock Crusher has stable and reliable performance, strong pressure resistance and load resistance during operation.
3. The main wear-resistant parts are made of high-quality wear-resistant alloy, which prolongs the service life of the equipment and reduces the production cost of the enterprise.
4. The optimized design of the crushing trajectory and the large eccentricity to improve the crushing ratio of the equipment make the Jaw Rock Crusher have higher crushing efficiency and higher output.
Technical Reference Data
| Model | Feed port size (mm) | Maximum feed particle size (mm) | Adjustment range of outlet (mm) | Production capacity (t/h) | Power (kw) | Rotating speed (r/min) | Weight (t) |
| XCE2540 | 250*400 | 210 | 20-80 | 5-20 | 15 | 300 | 2.8 |
| XCE4060 | 400*600 | 340 | 40-100 | 16-54 | 30 | 275 | 6.5 |
| XCE5075 | 500*750 | 425 | 50-100 | 30-85 | 55 | 275 | 10.3 |
| ※XCE40108 | 400*1080 | 340 | 40-100 | 30-100 | 75 | 250 | 10.8 |
| ※XCE5013 | 500*1300 | 425 | 50-120 | 50-150 | 90 | 275 | 15.6 |
| ※XCE5015 | 500*1500 | 425 | 50-120 | 60-185 | 110 | 275 | 18.3 |
| ※XCE5712 | 570*1200 | 475 | 50-130 | 80-210 | 132 | 275 | 17.8 |
| XCE6090 | 600*900 | 500 | 65-160 | 50-150 | 75 | 250 | 15.5 |
| XCE75106 | 750*1060 | 630 | 80-140 | 50-208 | 110 | 250 | 27.5 |
| XCE9012 | 900*1200 | 750 | 95-165 | 100-238 | 132 | 200 | 50 |
| XCE1012 | 1000*1200 | 850 | 105-175 | 295-350 | 160 | 200 | 52 |
| XCE1215 | 1200*1500 | 1020 | 150-300 | 300-800 | 220 | 180 | 100.8 |
