CE ISO9001 Dribble Conveyor Apron Feeder In Cement Plant Short Distance Transportation

70-200 TPH Apron Plate Feeder Stable Performance Short Distance Transportation

Product Principle

High-strength forged bulldozer chain with a pitch of 228.6 mm (9 inches) is used as the pulling part. Two chains are connected to a closed circuit by a pair of driving sprockets installed at the head of the body and a pair of tensioning wheels at the tail of the body. Each link of the two rows of chains is equipped with overlapping, Apron Plate Feeder chutes to form a continuous conveying line capable of carrying materials.Its self-weight and the weight of materials are supported by multiple rows of supporting wheels, chain pallets and slide beams installed on the machine body. The transmission system is connected to the reducer by the AC frequency-controlled motor, and then driven by the rising sleeve and the driving device directly connected to the low-speed operation of the transporting mechanism. Three special load-bearing plates are a group, with excellent load-bearing effect and no material jamming. The material discharged from the tail bin is transported along the conveying line to the front of the machine body and discharged to achieve the purpose of continuous and even feeding to the working machinery below.

Technical Reference Data

Material Inlet
