Hot Rolled Stainless Steel Pipe High Hardness 17-4PH SCH10-XXS
High Hardness 17-4PH Stainless Steel Pipe / Hot Rolled Stainless Steel Pipe / SS Pipe
17-4PH is a martensitic precipitation hardening stainless steel. The performance characteristic of 17-4PH is that it is easy to adjust the strength level, which can be adjusted by changing the heat treatment process. 17-4PH has good attenuation performance, strong resistance to corrosion fatigue and water droplets. Features: After heat treatment, the mechanical properties of the product are more perfect, and can reach a compressive strength of up to 1100-1300 Mpa (160-190 ksi). This grade cannot be used at temperatures higher than 300°C (572°F) or very low temperatures. It has good corrosion resistance to the atmosphere and diluted acids or salts.
About Stainless Steel 17-4 PH Pipe and Tube
Despite such excellent characteristics, 17-4 Ph Pipes are unsuitable for working under extremely high or low temperatures. It means in cryogenic applications where the temperature is above 572 degrees, and these pipes are unsuitable.
SS 17-4 PH Specification
Specifications : AISI 630 , AMS 5604 , AMS 5622 , AMS 5643 , ASTM A564 (630) ASTM A693 (630), ASTM A705 (630), MIL C-24111, MIL P-47183, MILS-81591.
Standard : ASTM, ASME and API
Sizes : 1/8” to 48”, Seamless Pipes up to 24”
Thickness : 0.4mm up to 30.00 mm
Length : Standard 6-6.1 meter length, 20 Ft, Custom Cut Lengths
Schedule : SCH 10, SCH20, SCH30, SCH40, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS
Types : Seamless / ERW / Welded / EFW / Fabricated / CDW
Form : Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes
End : Plain End, Beveled End, Treaded
Stainless Steel 17-4 PH Pipes & Tubing Chemical Composition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Cb+Ta |
| SS 17-4 PH | 0.07 | 1.0 max | 1.0 max | 0.03 | 3.0 – 5.0 | Bal | 3.0 – 5.0 | 15.0 – 17.5 | 5 X C / 0.45 |
Stainless Steel 17-4 PH Pipes & Tubes Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS |
| SS 17-4 PH | 1.4542 | S17400 |
Types of Stainless Steel 17-4 PH Pipe and Tube
| SS 17-4 PH Seamless Pipe | Stainless Steel DIN 1.4542 Seamless Pipe Stainless Steel UNS S17400 Seamless Pipe Stainless Steel 17-4 PH Seamless Pipes Austenitic Stainless Steel 17-4 PH Seamless Pipe AMS 5568 Steel 17-4 PH Seamless Pipe AISI 630 SS 17-4 PH Seamless Pipes |
| SS 17-4 PH Welded Pipe | Stainless Steel DIN 1.4542 Welded Pipe Stainless Steel UNS S17400 Welded Pipe Austenitic Stainless Steel 17-4 PH Welded Pipes Stainless Steel 17-4 PH Welded Pipe AMS 5568 Steel 17-4 PH Welded Pipes AISI 630 SS 17-4 PH Welded Pipes |
| SS 17-4 PH Round Pipe | Stainless Steel DIN 1.4542 Round Pipe Stainless Steel UNS S17400 Round Pipes Austenitic Stainless Steel 17-4 PH Round Pipes Stainless Steel 17-4 PH Round Pipe Austenitic Stainless Steel 17-4 PH Round Pipe AISI 630 SS 17-4 PH Round Pipes |
| SS 17-4 Seamless Tubes | Stainless Steel DIN 1.4542 Seamless Tubes Stainless Steel UNS S17400 Seamless Tubes Austenitic Stainless Steel 17-4 PH Seamless Tubing Stainless Steel 17-4 PH Seamless Tubes AMS 5568 Steel 17-4 PH Seamless Tubing AISI 630 SS 17-4 PH Seamless Tubes |
| SS 17-4 Welded Tubes | Stainless Steel DIN 1.4542 Welded Tubes Stainless Steel UNS S17400 Welded Tubes Austenitic Stainless Steel 17-4 PH Welded Tubing Stainless Steel 17-4 PH Welded Tubes AMS 5568 Steel 17-4 PH Welded Tubing AISI 630 SS 17-4 PH Welded Tubes |
| SS 17-4 Round Tubes | Stainless Steel DIN 1.4542 Round Tubes Stainless Steel UNS S17400 Round Tubes Austenitic Stainless Steel 17-4 PH Round Tubing SS 17-4 PH Round Tubes AMS 5568 Stainless Steel 17-4 PH Round Tubing AISI 630 Steel 17-4 PH Round Tubes |
| SS 17-4 PH Pipe | Stainless Steel DIN 1.4542 Pipe Stainless Steel UNS S17400 Pipes Austenitic Stainless Steel 17-4 PH Pipe Stainless Steel 17-4 PH Pipes AMS 5568 Steel 17-4 PH Pipes AISI 630 SS 17-4 PH Pipe |
| SS 17-4 PH Tube | Stainless Steel DIN 1.4542 Tubes Stainless Steel UNS S17400 Tube Austenitic Stainless Steel 17-4 PH Tubing SS UNS S17400 Tubes AISI 630 Steel 17-4 PH Tubes AMS 5568 Stainless Steel 17-4 PH Tubes |
Industry Application
Stainless Steel 17-4 PH Pipes and Tubing are extensively applied in extremely corrosive conditions in the below Industries.
- Oil & Gas Industry
- Petrochemicals Plants
- Chemical Plants
- Industrial Machinery
- Power Industry
- Paper & Pulp Industry
- Food Processing Industry
- Refineries
