TISCO 2B BA 430 Stainless Steel Coil 1000mm 1219mm 1500mm
430 Stainless Steel Coil TISCO Stainless Steel Roll 2B BA CR Coil SUS430 SS Coil
ASTM A276 Stainless Steel 430 Coils Supplier, Stainless Steel UNS S43000 Coils Manufacturer, Stainless Steel 430 Coil, UNS S43000 Stainless Steel Coils, ASTM A276 Stainless Steel 430 Coils, Stainless Steel 430 Coils, 430 Stainless Steel Coils, SS UNS S43000 Coils Exporter
Stainless Steel 430 Coils are non-hardened steel contain 17% chromium & 0.75% nickel and belong to ferrite group of steels. These stainless steel coils are famous for their outstanding corrosion resistance and good formability. As UNS S43000 SS Coils possess some top quality features, coils are broadly used in chemical applications.
430 Stainless Steel Coil Specifications:
| Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316Ti, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L |
| Thickness | 0.02mm – 5.0mm |
| Width | 3.2mm – 1500mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT |
| Type of Material | STAINLESS STEEL SOFT, DEEP DRAW, EXTRA DEEP DRAW, QUARTER HARD, HALF HARD, FULL HARD. |
| Form | Coil / Strip |
| Test Certificate | Yes. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Make | TISCO BAOSTEEL POSCO JISCO LISCO |
Chemical Composition of Stainless Steel 430 Coil
| Grade | C | Mn | Si | P | S | Cr | Ni | Mo | |
| 430 | Min | – | – | – | – | – | 16.0 | – | – |
| max | 0.12 | 1.00 | 1.00 | 0.040 | 0.030 | 18.0 | 0.75 | – |
ASTM A240 SS 430 Coil Mechanical Properties
| Grades | SS 430 |
| Tensile Strength (MPa) min | 450 |
| Yield Strength 0.2% Proof (MPa) min | 205 |
| Elongation (% in 50mm) min | 22 |
| Hardness Rockwell B (HR B) max | 89 |
| Hardness Brinell (HB) max | 183 |
Equivalent Grades of 430 Stainless Steel Coil
| STANDARD | UNS | JIS | WERKSTOFF NR. | AFNOR | BS | GOST | EN |
| SS 430 | S43000 | SUS 430 | 1.4016 | – | – | – | – |
What are the applications that 430 stainless steel coils can be used?
430 stainless steel coil is a kind of high quality alloy, which can be used in the manufacture of various stainless steel end products.
The main applications of 430 stainless steel coil:
- Chemical industry: chemical storage tank, vessel, heat exchanger;
- Food industry: liquid storage tank, evaporator;
- Agricultural industry: steam boiler and condenser;
- Papermaking industry: boiler tube;
- Metallurgy industry: heat-exchanger tube in metallurgical industries.
Features of 430 stainless steel coils
430 stainless steel coil is the ferrite stainless steel which is used in a variety of applications due to its strength and ductility.
Features of 430 Stainless Steel Coils:
- High Strength
- Easy Formability
- Excellent Corrosion Resistance
- Good Weldability
- Resistance to Stress Corrosion Cracking (SCC)
