904L Cold Rolled Stainless Steel Sheet In Coil UNS N08904 Hot Rolled
904L Stainless Steel Coil UNS N08904 SS Coil Cold Rolled Hot Rolled Stainless Steel 904L Coil
ASTM B625 Stainless Steel 904L Coils Supplier, Stainless Steel UNS N08904 Coils Manufacturer, Stainless Steel 904L Coil, UNS N08904 Stainless Steel Coils, ASTM B625 Stainless Steel 904L Coils, Stainless Steel 904L Coils, 904L Stainless Steel Coils, SS UNS N08904 Coils
Grade 904L Stainless Steel Coils are made up of non-stabilized austenitic stainless contains 25% chromium and 4.5% nickel with low carbon content. This alloy stainless steel coil has an addition of copper to improve resistance to strong reducing acids like sulphuric acids. Moreover, these Stainless Steel 904L Coils are also resistant to stress corrosion cracking and crevice corrosion.
Non-magnetic UNS N08904 Stainless Steel Coils possess excellent toughness, formability, and weldability due to low carbon content. We offered these type 904L SS Coils in several industries such as oil & gas refineries, marine appliances, paper & pulp processing, food processing, heat exchangers, boiler industries and many more. Our manufacturing unit manufactured these coils in Indian as well as International Standards including ASME, ASTM, ANSI, AISI, BS, IS, DIN, JIS & more
904L Stainless Steel Coil Specifications:
| Grades | Stainless Steel J1, J2, J4, 201, 202, 301, 304, 304H, 304L, 309, 309S, 310, 310S, 316, 316L, 316Ti, 321, 321H, 347, 409, 410, 410S, 420, 430, 441, 904L |
| Thickness | 0.02mm – 5.0mm |
| Width | 3.2mm – 1500mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT |
| Type of Material | STAINLESS STEEL SOFT, DEEP DRAW, EXTRA DEEP DRAW, QUARTER HARD, HALF HARD, FULL HARD. |
| Form | Coil / Strip |
| Test Certificate | Yes. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
Chemical Composition of Stainless Steel 904L Coil
| Grade | C | Mn | Si | P | S | Cr | Ni | Mo | N | Cu | |
| 904L | Min | – | – | – | – | – | 19.0 | 23.00 | 4.00 | 0.10 | 1.00 |
| max | 0.20 | 2.00 | 1.00 | 0.045 | 0.035 | 23.0 | 28.00 | 5.00 | 0.25 | 2.00 |
ASTM A240 SS 904L Coil Mechanical Properties
| Grades | SS 904L |
| Density | 8 |
| Melting Point | 1300 – 1390 ℃ |
| Tensile Strength | 490 |
| Yield Strength (0.2%Offset) | 220 |
| Elongation | 35% min |
| Hardness (Brinell) | – |
Equivalent Grades of 904L Stainless Steel Coil
| STANDARD | UNS | JIS | WERKSTOFF NR. | AFNOR | BS | GOST | EN |
| SS 904L | N08904 | SUS 904L | 1.4539 | Z2 NCDU 25-20 | 904S13 | – | X1NiCrMoCu25-20-5 |
Industries and applications where our 904L SS Coil is used.
Chemicals, Petrochemicals, Oil & Natural Gas Organization, Fats, Fertilizers, Sugar Mills & Distilleries, Cement Industries, Ship Builders, Paper Industries, Pumps, Automation, Paints, Steel Industries, etc.
