EN 10204-3.1 Certificated Stainless Steel Bar Round 1.4301 10-300mm
EN 10204-3.1 Certificated 1.4301 Stainless Steel Round Bar / Stainless Steel Rod SS Bar Diameter 10-300mm
| Description | High quality 1.4301 sus304 Stainless Steel round Bar in stock | |
| Material |
304,304L,309S,310S,316,316L,316Ti,317,317L,321,347H,201,202,405,409, 410,420,430,etc |
|
| Type | Round,square,hexagonal,flat,angle | |
| Surface | Pickled,Black,Bright,Polishing,Blasting,etc | |
| Specifications | Round bar | Diameter: 3mm~800mm |
| Angle bar | Size: 3mm*20mm*20mm~12mm*100mm*100mm | |
| Square bar | Size: 4mm*4mm~100mm*100mm | |
| Flat bar | Thickness: 2mm~100mm | |
| Width: 10mm~500mm | ||
| Hexagonal | Size: 2mm~100mm | |
| MOQ | 500 kilograms | |
| Length | 6m,5.8m,3m or as required | |
| Price Term | EX-Work, FOB, CFR, CIF,CNF | |
| Payment Term | T/T,L/C, Western union | |
| Market |
Europe,South America, Africa ,Oceania ,such as :Chile,Spain, and so on. |
|
| Package | Bundled,wooden box for export standard package. | |
| Delivery Time | Normally according to the order quantity | |
DIN EN 1.4301 stainless steel (X5CrNi18-10) is a conventional austenitic stainless steel with good resistance to atmospheric, organic and inorganic chemicals. This material is widely used due to its excellent intergranular corrosion resistance, good cold deformability, good deep drawability and weldability.
1.4306 (X2CrNi19-11) and 1.4307 (X2CrNi18-9) are ultra-low carbon versions of 1.4301. The purpose is to improve the corrosion resistance after welding and prevent carbide precipitation caused by stress relief for a long time.
Grade Specification of our Stainless STeel Bar
| Stainless Steel Grades | ||||
| EN-DIN standard steel grade | EN-standard steel grade | ASTM/AISIstandard steel grade | UNS | GB-standard steel grade |
| 1.431 | X10CrNi18-8 | 301 | ||
| 1.4318 | X2CrNiN18-7 | 301LN | ||
| 1.4307 | X2CrNi18-9 | 304L | S30403 | |
| 1.4306 | X2CrNi19-11 | 304L | S30403 | 00Cr18Ni9 |
| 1.4311 | X2CrNiN18-10 | 304LN | S30453 | |
| 1.4301 | X5CrNi18-10 | 304 | S30400 | 06Cr19Ni10 |
| 1.4948 | X6CrNi18-11 | 304H | S30409 | |
| 1.4303 | X5CrNi18 12 | 305 | ||
| 1.4541 | X6CrNiTi18-10 | 321 | S32100 | 0Cr18Ni11Ti |
| 1.4878 | X12CrNiTi18-9 | 321H | S32109 | |
| 1.4404 | X2CrNiMo17-12-2 | 316L | S31603 | 00Cr17Ni14Mo2 |
| 1.4432 | X2CrNiMo17-12-3 | 316L | S31603 | 00Cr17Ni14Mo2 |
| 1.4435 | X2CrNiMo18-14-3 | 316L | S31603 | 00Cr17Ni14Mo2 |
| 1.4401 | X5CrNiMo17-12-2 | 316 | S31600 | 0Cr17Ni12Mo2 |
| 1.4436 | X3CrNiMo17-13-3 | 316 | S31600 | 0Cr17Ni12Mo2 |
| 1.4406 | X2CrNiMoN17-12-2 | 316LN | S31635 | |
| 1.4571 | X6CrNiMoTi17-12-2 | 316Ti | S31635 | |
| 1.4429 | X2CrNiMoN17-13-3 | 316LN | S31653 | |
| 1.4438 | X2CrNiMo18-15-4 | 317L | S31703 | |
| X10CrNiTi189 | 347 | 0Cr18Ni11Nb | ||
| 1.4512 | X6CrTi12 | 409 | 0Cr11Ti | |
| S41000 | 0Cr13 | |||
| 410 | 1Cr13 | |||
| 420J1 | 2Cr13 | |||
| 1.4016 | X6Cr17 | 430 | 1Cr17 | |
| 1.4118 | X40CrMo15 | 440A | S44002 | 8Cr13 |
| 1.4112 | 440B | S44004 | 9Cr13 | |
| 1.4125 | 440C | S44003 | 11Cr18 | |
| 440F | S44020 | |||
| 1.4539 | X1NiCrMoCu25-20-5 | 904L | N08904 | 00Cr20Ni25Mo4.5Cu |
| 1.4547 | X1CrNiMoCuN20-18-7 | S31254 | ||
Chemical Composition of our stainless steel bar
| Chemical composition | |||||
| Grade | C | Si | Mn | Cr | Ni |
| 304 | ≤0.07 | ≤1.00 | ≤2.0 | 18.00~20.00 | 8.00~10.50 |
| 304L | ≤0.030 | ≤1.00 | ≤2.0 | 18.00~20.00 | 9.00~13.00 |
| 310S | ≤0.08 | ≤1.00 | ≤2.0 | 24.00~26.00 | 19.00~22.00 |
| 316 | ≤0.08 | ≤1.00 | ≤2.0 | 16.00~18.00 | 10.00~14.00 |
| 316L | ≤0.03 | ≤1.00 | ≤2.0 | 16.00~18.00 | 12.00~15.00 |
| 321 | ≤0.08 | ≤1.00 | ≤2.0 | 17.00~19.00 | 9.00~13.00 |
| 904L | ≤0.02 | ≤1.00 | ≤2.0 | 19.00~23.00 | 23.00~28.00 |
| 2205 | ≤0.03 | ≤1.00 | ≤2.0 | 22.00~23.00 | 4.5~6.5 |
| 2507 | ≤0.03 | ≤0.08 | ≤1.20 | 24.00~26.00 | 6.00~8.00 |
