| Steel Grade | Ni% Max. | Cr% Max. | C% Max. | Si% Max. | Mn% Max. | P% Max. | S% Max. | Mo% Max. | Ti% Max. | Other |
| SUS301 | 6.0~8.0 | 16.0~18.0 | 0.15 | 1 | 2 | 0.045 | 0.03 | - | - | - |
| SUS304 | 8.0~10.5 | 18.0~20.0 | 0.08 | 1 | 2 | 0.045 | 0.03 | - | - | - |
| SUS304L | 9.0~13.0 | 18.0~20.0 | 0.03 | 1 | 2 | 0.045 | 0.03 | - | - | - |
| SUS310S | 19.0~22.0 | 24.0~26.0 | 0.08 | 1.5 | 2 | 0.045 | 0.03 | - | - | - |
| SUS316L | 12.0~15.0 | 16.0~18.0 | 0.03 | 1 | 2 | 0.045 | 0.03 | 2.0~3.0 | - | - |
| SUS321 | 9.0~13.0 | 17.0~19.0 | 0.08 | 1 | 2 | 0.045 | 0.03 | - | 5xC MIN. | - |
| SUH409L | 0.6 | 10.5~11.75 | 0.03 | 1 | 1 | 0.04 | 0.03 | - | 6xC~0.75 | - |
| SUS410S | 0.6 | 11.5~13.5 | 0.08 | 1 | 1 | 0.04 | 0.03 | - | - | - |
| SUS420J2 | 0.6 | 12.0~14.0 | 0.08 | 1 | 1 | 0.04 | 0.03 | - | - | - |
| SUS430 | 0.6 | 16.0~18.0 | 0.12 | 0.75 | 1 | 0.04 | 0.03 | - | - | - |
Cold Rolled Stainless Steel Strip Roll 0.3 - 3.0mm Slit Cutting Without Burr 8K
Price:
2400 - 3500 USD/Ton
MOQ:
2 Ton
Delivery Time:
5 - 12 days based on the quantity
Brand:
TISCO
Product Description
Stainless Steel Strip Roll Thickness 0.3 - 3.0mm Cold Rolled Slit Cutting without Burr
Stainless Steel Strip
Stainless steel strip is a steel product used in applications that require durable and corrosion-resistant material. It is mainly used in construction, manufacturing, home, and commercial cooking equipment and appliances. We are a supplier of stainless steel strips and offer many different sizes.
Stainless steel is a low-cost and corrosion-resistant material with a high level of durability. It is ideal for both residential and marine applications. Not only is it durable and long-lasting with a perfect surface finish, but it also has excellent strength.
Product Specification and Steel Grade
| ASTM | JIS | AISI | EN | Mill's Standard | |
| Grade | S30100 S30400 S30403 S31008 S31603 S32100 S41008 S43000 S43932 S44400 S44500 |
SUS301 SUS304 - SUS310S - SUS321 SUS410S SUS430 - SUS444 SUS430J1L |
301 304 304L 310S 316L 321 410S 430 - 444 - |
1.4310 1.4301 1.4307 1.4845 1.4404 1.4541 - 1.4016 1.4510 1.4521 - |
201 202 204Cu3 |
Other specifications are also available up to request
Hot Rolled Strip Available Size
- Width: 16.0~609.6 mm
- Thickness: 2.5~10.0 mm
- Available Steel Grade: 304, 304L, 316L
- Surface Finish: No.1
Cold Rolled Strip Available Size
- Width: 4.0~609.6 mm
- Thickness: 0.1~3.0 mm
- Available Steel Grade: 201, 202, 204 Cu3, 301, 304, 304L, 310S, 316L, 321, 409L, 410S, 420J2, 430, 439, 441, 444, 445
- Surface Finish: 2B, 2D, BA, No.3, No.4, No.5, SB, HL
Application
stainless steel strip is widely used in compressor valves, knives, scissors and spring applications. 304 stainless steel strip is used in variety of products including forks and knives.
Tolerance of Width
| W < 100 mm | 100 mm ≦ W < 1000 mm |
| ± 0.10 mm | ± 0.25 mm |
Chemical Composition & Mechanical Property :
Chemical Composition (For Reference)
ASTM Specification
| Steel Grade | Ni% Max. | Cr% Max. | C% Max. | Si% Max. | Mn% Max. | P% Max. | S% Max. | Mo% Max. | Ti% Max. | Other |
| S30100 | 6.0~8.0 | 16.0~18.0 | 0.15 | 1 | 2 | 0.045 | 0.03 | - | - | N: 0.1Max. |
| S30400 | 8.0~10.5 | 17.5~19.5 | 0.07 | 0.75 | 2 | 0.045 | 0.03 | - | - | N: 0.1Max. |
| S30403 | 8.0~12.0 | 17.5~19.5 | 0.03 | 0.75 | 2 | 0.045 | 0.03 | - | - | N: 0.1Max. |
| S31008 | 19.0~22.0 | 24.0~26.0 | 0.08 | 1.5 | 2 | 0.045 | 0.03 | - | - | - |
| S31603 | 10.0~14.0 | 16.0~18.0 | 0.03 | 0.75 | 2 | 0.045 | 0.03 | 2.0~3.0 | - | N: 0.1Max. |
| S32100 | 9.0~12.0 | 17.0~19.0 | 0.08 | 0.75 | 2 | 0.045 | 0.03 | - | 5(C+N)~0.70 | N: 0.1Max. |
| S41000 | 0.75 | 11.5~13.5 | 0.08~0.15 | 1 | 1 | 0.04 | 0.03 | - | - | - |
| S43000 | 0.75 | 16.0~18.0 | 0.12 | 1 | 1 | 0.04 | 0.03 | - | - | - |
| S43932 | 0.5 | 17.0~19.0 | 0.03 | 1 | 1 | 0.04 | 0.03 | - | - | N:0.03Max. Al:0.15Max. Nb+Ti = [ 0.20 + 4 ( C + N ) ] ~ 0.75 |
Mechanical Property (For Reference)
JIS Specification
| Steel Grade | N/mm 2 MIN. Tensile Stress |
N/mm 2 MIN. Proof Stress |
% MIN. Elongation |
HRB MAX. Hardness |
Bendability: Bending Angle |
Bendability: Inside Radius |
| SUS301 | 520 | 205 | 40 | 95 | No Require | - |
| SUS304 | 520 | 205 | 40 | 90 | No Require | - |
| SUS304L | 480 | 175 | 40 | 90 | No Require | - |
| SUS310S | 520 | 205 | 40 | 90 | No Require | - |
| SUS316L | 480 | 175 | 40 | 90 | No Require | - |
| SUS321 | 520 | 205 | 40 | 90 | No Require | - |
| SUH409L | 360 | 175 | 25 | 80 | 180° | 0.5t (t＜8mm) 1.0t (t＞8mm) |
| SUS410S | 410 | 205 | 20 | 88 | 180° | 1.0 time the thickness |
| SUS420J2 | 540 | 225 | 18 | 99 | No Require | - |
| SUS430 | 420 | 205 | 22 | 88 | 180° | 1.0 time the thickness |
ASTM Specification
| Steel Grade | N/mm 2 MIN. Tensile Stress |
N/mm 2 MIN. Proof Stress |
% MIN. Elongation MIN. |
HRB MAX. Hardness |
HBW MAX. Hardness |
Bendability: Bending Angle |
Bendability: Inside Radius |
| S30100 | 515 | 205 | 40 | 95 | 217 | No Require | - |
| S30400 | 515 | 205 | 40 | 92 | 201 | No Require | - |
| S30403 | 485 | 170 | 40 | 92 | 201 | No Require | - |
| S31008 | 515 | 205 | 40 | 95 | 217 | No Require | - |
| S31603 | 485 | 170 | 40 | 95 | 217 | No Require | - |
| S32100 | 515 | 205 | 40 | 95 | 217 | No Require | - |
| S41000 | 450 | 205 | 20 | 96 | 217 | 180° | - |
| S43000 | 450 | 205 | 22 | 89 | 183 | 180° | - |
| S43932 | 415 | 205 | 22 | 89 | 183 | 180° | - |
