17-4PH Stainless Steel Plate Hot Rolled 10 - 150mm SS Plate UNS S17400 Custom Cutting

Price Negotiable

Price: 4000-6000 USD/Ton

MOQ: 500 kgs

Delivery Time: 5 - 12 days based on the quantity

Brand: TISCO BAOSTEEL

Product Description

17-4PH Stainless Steel Plate Hot Rolled 10 - 150mm SS Plate UNS S17400 Custom Cutting

Specification of SS 17-4PH plate

specifications	ASTM A240 / ASME SA240, EN 10088-2
Standard	ASME, ASTM, DIN, BS, EN
Thickness	1 to 200mm
Length	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface	2B, etching, BA,, NO.4, NO.8, Brush, NO.1, mirror, 8K, hair line, embossed, 2D, checkered, sand blast, etc
Origin	China
Technique	Cold Rolled and Hot Rolled
Width	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc
Stainless Steel Sheet Finish	Cold rolled sheet (CR), SATIN (Met with Plastic Coated), BA NO(8), Hot rolled plate (HR), 2B, 2D
MTC	Available as per EN 10204 3.1, Mill Test Certificate
Brand Name	TISCO BAOSTEEL POSCO JISCO LISCO
Container	40ft HC: 12032m
Form	Coils, Foils, Shim Sheets, Rolls, Plain Sheets, Ring (Flange), Strip, Perforated Sheets, Blank (Circle), Chequered Plate, Flats, etc.
Price term	CFR, Ex-Work, FOB, CNF, CIF
Size	40ft GP: 12032mm x 2352mm x 2393mm
Size	20ft GP: 5898mm x 2352mm x 2393mm

Detail Size of 17-4PH Stainless Steel Plate We have

Grade

17-4PH

Thickness

Cold rolled: 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm

Hot Rolled : 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm 14.0mm 16.0mm 20.0mm 25mm 30mm 35mm 40mm 45mm 50mm 55mm 60mm

Standard Size

1000*2000mm 1219*2438mm 1500*6000mm

Alloy 17-4 is a chromium-copper precipitation hardening stainless steel that is used for applications requiring high strength and a moderate level of corrosion resistance. It is one of the most widely used precipitation hardening grades, as it has high strength hardness up to about 572°F while demonstrating good corrosion resistance in all heat treated conditions. Alloy 17-4 has adequate resistance to atmospheric corrosion or in diluted acid salts where its corrosion resistance is equivalent to Alloy 304 or 430. Alloy 17-4 can be heat treated to a variety of temperatures to develop a wide range of properties. Its mechanical properties can be optimized with heat treatment where very high yield strength up to 180 ksi can be achieved. Alloy 17-4 should not be used at temperatures above 572°F or at very low temperatures.

Chemical Composition

Carbon	0.07% (Max)
Silicon	1.00% (Max)
Manganese	1.00% (Max)
Phosphorous	0.040% (Max)
Sulfur	0.030% (Max)
Chromium	15%-17.5%
Molybdenum	0.50% (Max)
Nickel	3%-5%
Copper	3%-5%

Physical Properties

Condition	Tensile	Yield	Enlongation	Reduction of Area	Hardness
H900	190KSI	170KSI	10%	35%	35 HRC
H1025	155KSI	145KSI	12%	45%	40 HRC
H1075	145	125	13	45	33-39 HRC
H1150	135	105	16	50	28-37 HRC
H1150D	125	105	16	50	25-33 HRC

APPLICATIONS:

Alloy 17-4 is commonly used for applications requiring high strength and a moderate level of corrosion resistance. Some applications that frequently use Alloy 17-4 include:
