Heat Resistant Stainless Steel Plate Grade 314 / UNS S31400 SS Plate Thickness 3.0 - 60.0mm
Heat Resistant Stainless Steel Plate Grade 314 / UNS S31400 SS Plate Thickness 3.0 - 60.0mm
Specification of SS 314 plate
|
specifications
|
ASTM A240 / ASME SA240, EN 10088-2 |
|---|---|
|
Standard
|
ASME, ASTM, DIN, BS, EN |
|
Thickness
|
1 to 200mm |
|
Length
|
2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
|
Surface
|
2B, etching, BA,, NO.4, NO.8, Brush, NO.1, mirror, 8K, hair line, embossed, 2D, checkered, sand blast, etc |
|
Origin
|
China |
|
Technique
|
Cold Rolled and Hot Rolled |
|
Width
|
1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc |
|
Stainless Steel Sheet Finish
|
Cold rolled sheet (CR), SATIN (Met with Plastic Coated), BA NO(8), Hot rolled plate (HR), 2B, 2D |
|
MTC
|
Available as per EN 10204 3.1, Mill Test Certificate |
|
Brand Name
|
TISCO BAOSTEEL POSCO JISCO LISCO |
|
Container
|
40ft HC: 12032m |
|
Form
|
Coils, Foils, Shim Sheets, Rolls, Plain Sheets, Ring (Flange), Strip, Perforated Sheets, Blank (Circle), Chequered Plate, Flats, etc. |
| Price term | CFR, Ex-Work, FOB, CNF, CIF |
|
Size
|
40ft GP: 12032mm x 2352mm x 2393mm |
| 20ft GP: 5898mm x 2352mm x 2393mm |
What is 314 Stainless Steel?
314 stainless steel is an alloy of iron, nickel and chromium. It offers superior corrosion resistance and high-temperature strength compared to other steel alloys. 314 stainless steel is often used in food processing equipment, chemical tanks, heat exchangers and industrial appliances due to its excellent performance characteristics.
314 Stainless Steel Composition
314 stainless steel is austenitic stainless steel composed of iron, chromium, nickel, molybdenum, and silicon. Like other stainless steel types, it has high corrosion resistance and is known for its exceptional strength and durability.
| Element | Content (%) |
|---|---|
| Iron, fe | Balance |
| Chromium, Cr | 23-26 |
| Nickel, Ni | 19-22 |
| Manganese, Mn | 2 |
| Silicon, Si | 1.5-3 |
| Carbon, C | 0.25 |
| Sulfur, S | 0.03 |
| Phosphorous, P | 0.045 |
Equivalent materials to grade 314 stainless steel are given below.
| AFNOR Z 12 CNS 25.20 | DIN 1.4841 | UNI X 16 CrNiSi 25 20 | UNI X 22 CrNi 25 20 | JIS SUS Y 31O |
| B.S. 310 S 24 | AMS 5522 | AMS 5652 | ASTM A276 | ASTM A314 |
| ASTM A473 | ASTM A580 | SAE 30314 | SAE J405 (30314) |
Applications
Grade 314 steel is widely used in the following applications:
- Radiant tubes
- Equipment for furnaces
- Heat treatment components
- Annealing and carburizing boxes
