400 Series Stainless Steel Plate & Sheet Grade 409L 410 416 420 430 431 436L 439 441 444 SS Plate
400 Series Stainless Steel Plate & Sheet Grade 409L 410 416 420 430 431 436L 439 441 444 SS Plate
| Products | Stainless Steel Plate |
| Thickness | 0.4 - 30.0mm |
| Width | 1000mm 1219mm 1500mm 1800mm 2000mm or other width as request |
| Length | 2000mm 2438mm 3000mm 6000mm or other length as request |
| Grade | 201 202 301 304 304L 304H 309S 310S 316L 316Ti 317L 321 347 409L 410 420 430 431 436L 439 441 443 444 2205 2507 904L 600 625 800 825 718 253MA 254SMO.etc |
| Service | Laser Cutting, Surface processing, bending |
| Brand | TISCO BAOSTEEL POSCO LISCO JISCO |
| Standard | ASTM JIS GB DIN EN BS |
| Certificate | ISO MTC C/O F/E |
| Packing | Wooden pallets and waterproof paper |
| Deliver time | 5 - 15 days |
| Loading port | Shanghai Port |
400 SERIES STAINLESS
The 400 series group of stainless steels has an 11 percent chromium and 1-percent manganese increase, above the 300 series group. The 400 series is susceptible to rust and corrosion under some conditions. Heat-treating will harden the 400 series. The 400 series of stainless steels have higher carbon content, giving it a martensitic crystalline structure. This provides high strength and high wear resistance. Martensitic stainless steels aren’t as corrosion resistant as the austenitic types
400 Series Stainless Steel Grade: 409L 410 410S 420 430 434 436L 439 441 443 444
Application of 400 Series Stainless Steel Plate
The 400 series includes both ferritic and martensitic steels.
Ferritic steels: non-hardening steels, ideal for conditions in elevated temperatures. Typical applications for ferritic stainless steels include petrochemical, automotive exhaust systems, heat exchanges, furnaces, appliances and food equipment to name a few.
Martensitic steels: able to be hardened, ideal for a wide variety of common uses. Martensitic stainless steels are used extensively in cutlery, sport knives and multi-purpose tools.
The table below shows common types of 400 series steel:
| 400 Series Applications | |
|---|---|
| Type 405 | a ferritic steel, used especially for welding applications |
| Type 408 | heat-resistant; poor corrosion resistance; 11% chromium, 8% nickel. |
| Type 409 | cheapest type; used for automobile exhausts; ferritic (iron/chromium only). |
| Type 410 | martensitic (high-strength iron/chromium). Wear-resistant, but less corrosion-resistant. |
| Type 416 | easy to machine due to additional sulfur |
| Type 420 | Cutlery Grade martensitic; Excellent polishability. |
| Type 430 | decorative steel, used for automotive trim; ferritic. Good formability, but with reduced temperature and corrosion resistance. |
| Type 440 | a higher grade of cutlery steel, with more carbon in it, which allows for much better edge retention when the steel is heat-treated properly. |
| Type 446 | For elevated temperature service |
ADVANTAGES AND CHARACTERISTICS OF 400 SERIES STAINLESS STEEL
Ferritic, or nonhardenable stainless steels, are classified in the 400 series. This series is known for:
- superior corrosion resistance
- resistance to scaling at elevated temperatures
- inherent strength greater than carbon steels
- provide an advantage in many applications where thinner materials and reduced weight are necessary
- nonhardenable by heat treating
- always magnetic
Martensitic, or hardenable stainless steels, are classified in the 400 series. This series is known for:
- higher levels of carbon than ferritics
- ability to be heat treated to a wide range of hardness and strength levels
- excellent corrosion resistance
- easily machined
- good ductility
