EN 10204-3.1 Certificated Hot Rolled Stainless Steel Plate Grade AISI304L / UNS S30403
EN 10204-3.1 Certificated Hot Rolled Stainless Steel Plate Grade AISI304L / UNS S30403
| Products | Stainless Steel Plate |
| Thickness | 0.6 - 60.0mm |
| Width | 1000mm 1219mm 1500mm 1800mm 2000mm or other width as request |
| Length | 2000mm 2438mm 3000mm 6000mm or other length as request |
| Grade | 201 202 301 304 304L 304H 309S 310S 316L 316Ti 317L 321 347 409L 410 420 430 431 436L 439 441 443 444 2205 2507 904L 600 625 800 825 718 253MA 254SMO.etc |
| Service | Laser Cutting, Surface processing, bending |
| Brand | TISCO BAOSTEEL POSCO LISCO JISCO |
| Standard | ASTM JIS GB DIN EN BS |
| Certificate | ISO MTC C/O F/E |
| Packing | Wooden pallets and waterproof paper |
| Deliver time | 5 - 15 days |
| Loading port | Shanghai Port |
304l sTAINLESS sTEEL pLATE IN Stock
| 0.6*1000*2000mm | 1.0*1219*2438mm | 14.0*1500*6000mm |
| 0.8*1000*2000mm | 1.2*1219*2438mm | 16.0*1500*6000mm |
| 1.0*1000*2000mm | 1.5*1219*2438mm | 20.0*1500*6000mm |
| 1.2*1000*2000mm | 2.0*1219*2438mm | 4.0*2000*6000mm |
| 1.5*1000*2000mm | 2.5*1219*2438mm | 5.0*2000*6000mm |
| 2.0*1000*2000mm | 3.0*1219*2438mm | 6.0*2000*6000mm |
| 2.5*1000*2000mm | 4.0*1500*6000mm | 8.0*2000*6000mm |
| 3.0*1000*2000mm | 5.0*1500*6000mm | 10.0*2000*6000mm |
| 0.4*1219*2438mm | 6.0*1500*6000mm | 12.0*2000*6000mm |
| 0.5*1219*2438mm | 8.0*1500*6000mm | 14.0*2000*6000mm |
| 0.6*1219*2438mm | 10.0*1500*6000mm | 16.0*2000*6000mm |
| 0.8*1219*2438mm | 12.0*1500*6000mm |
304L Stainless Steel
Type 304L is the low carbon version of Stainless steel 304. It is used in heavy gauge components for improved weldability. Some products such as plate and pipe may be available as “dual certified” material that meets the criteria for both 304 and 304L.
Chemical Composition of Stainless Steel 304L
Table 1. Chemical composition for 304 stainless steel alloys
| % | 304 | 304L | 304H |
| C | 0.0 - 0.07 | 0.0 - 0.03 | 0.04 - 0.08 |
| Mn | 0.0 - 2.0 | 0.0 - 2.00 | 0.0 - 2.0 |
| Si | 0.0 - 1.00 | 0.0 - 1.00 | 0.0 - 1.0 |
| P | 0.0 - 0.05 | 0.0 - 0.05 | 0.0 - 0.04 |
| S | 0.0 - 0.03 | 0.0 - 0.02 | 0.0 - 0.02 |
| Cr | 17.50 - 19.50 | 17.50 - 19.50 | 17.00 - 19.00 |
| Ni | 8.00 - 10.50 | 8.00 - 10.50 | 8.00 - 11.00 |
| Fe | Balance | Balance | Balance |
| N | 0.0-0.11 | 0.0-0.11 | 0.0 - 0.10 |
Properties of Stainless Steel 304
Mechanical Properties of Stainless Steel 304
Table 2a. Mechanical properties for 304 stainless steel alloys - sheet up to 8 mm thick
| Grade | 304 | 304L | 304H |
| Tensile Strength (MPa) | 540 - 750 | 520 - 700 | - |
| Proof Stress (MPa) | 230 Min | 220 Min | - |
| Elongation A50 mm | 45 Min % | 45 Min % | - |
Table 2b. Mechanical properties for 304 stainless steel alloys - plate from 8 - 75 mm thick
| Grade | 304 | 304L | 304H |
| Tensile Strength (MPa) | 520 - 720 | 500 - 700 | - |
| Proof Stress (MPa) | 210 Min | 200 Min | - |
| Elongation A5 | 45 Min % | 45 Min % | - |
Table 2c. Mechanical properties for 304 stainless steel alloys - bar and section up to 160 mm diameter / thickness
| Grade | 304 | 304L | 304H |
| Tensile Strength (MPa) | 500 - 700 | 500 - 700 | 500 - 700 |
| Proof Stress (MPa) | 190 | 175 Min | 185 Min |
| Elongation A50 mm | 45 Min % | 45 Min % | 40 Min % |
| Hardness Brinell | 215 Max HB | 215 Max HB | - |
Alloy Designations
Stainless steel 304 also corresponds to the following standard designations and specifications:
| Euronorm | UNS | BS | En | Grade |
| 1.4301 | S30400 |
304S15 304S16 304S31 |
58E | 304 |
| 1.4306 | S30403 | 304S11 | - | 304L |
| 1.4307 | - | 304S11 | - | 304L |
| 1.4311 | - | 304S11 | - | 304L |
| 1.4948 | S30409 | 304S51 | - | 304H |
Applications of Stainless Steel 304L
Stainless steel 304L is typically used in:
- Sinks and splashbacks
- Saucepans
- Cutlery and flatware
- Architectural panelling
- Sanitaryware and troughs
- Tubing
- Brewery, dairy, food and pharmaceutical production equipment
- Springs, nuts, bolts and screws
Supplied Forms
Stainless steel 304 is typically supplied in the following forms:
- Sheet
- Strip
- Tube
- Quarto plate
- Bar
- Fittings & Flanges
- Pipe
- Plate
