EN 1.4529 Stainless Steel Plate UNS N08926 Alloy Sheet Thickness 0.6 - 16.0mm from BAOSTEEL
EN 1.4529 Stainless Steel Plate UNS N08926 Alloy Sheet Thickness 0.6 - 16.0mm from BAOSTEEL
Incoloy 926 (N08926) nickel alloy is a high corrosion resistant super austenitic stainless steel containing high Cr and high Mo. It maintains good corrosion resistance in harsh environments such as high temperature, sea water or flue gas desulfurization equipment. In some cases, it is even comparable to Hastelloy and titanium.
As a highly economical stainless steel featuring high corrosion resistance, Incoloy 926 (N08926) is highly resistant to pitting and crevice corrosion in halide media and sulfur-containing hydrogen environments. Incoloy 926 is also resistant to chloride stress corrosion, with good corrosion resistance in both oxidizing and reducing media. It has excellent stability and slightly better mechanical properties than 904L, suitable to be used for pressure vessel manufacturing under temperatures from -196°C to 400 °C.
Incoloy 926 (N08926) nickel-based alloy contains 14.0-18.0% Cr and 24.0-26.0% Ni. It is a nickel-based alloy containing titanium and aluminum, with enough chromium to form and maintain a sufficient scale of chromium oxide to protect it under high temperature conditions. Incoloy 926 is more heat resistant than typical chrome-nickel stainless steel such as 304. The high nickel contained within gives it better oxidation resistance than the standard 18-8 type stainless steel. Its oxidation resistance is equivalent to (if not higher than) the higher-grade alloys used at temperatures up to 1900 degrees Fahrenheit (1038 °C).
More Specification of Alloy 926
| Products | Stainless Steel Plate |
| Thickness | 0.6 - 60.0mm |
| Width | 1000mm 1219mm 1500mm 1800mm 2000mm or other width as request |
| Length | 2000mm 2438mm 3000mm 6000mm or other length as request |
| Grade | 201 202 301 304 304L 304H 309S 310S 310H 316L 316Ti 317L 321 347 409L 410 420 430 431 436L 439 441 443 444 2205 2507 904L 600 625 800 825 718 253MA 254SMO Nitronic 60 925 926.etc |
| Service | Laser Cutting, Surface processing, bending |
| Brand | TISCO BAOSTEEL POSCO LISCO JISCO |
| Standard | ASTM JIS GB DIN EN BS |
| Certificate | ISO MTC C/O F/E |
| Packing | Wooden pallets and waterproof paper |
| Deliver time | 5 - 15 days |
| Loading port | Shanghai Port |
UNS N08926 Stainless Steel Strip Chemical Composition
The chemical components of grade UNS N08926 stainless steel strip is summarized in the following table:
| Grade | Standard | C | Si | Mn | P | S | Cr | Ni | Mo |
| UNS N08926 | ASTM | ≤0.02 | ≤0.50 | ≤1.00 | ≤0.030 | ≤0.010 | 19.00-21.00 | 24.00-26.00 | 6-7 |
Alloy 926 Sheet and Plate Manufacturer - Mechanical Properties:
| Properties | Metric | Imperial |
| Tensile strength | ≥648 MPa | ≥94000 psi |
| Yield strength | ≥296 MPa | ≥43000 psi |
| Modulus of elasticity | 192 GPa | 27800 ksi |
| Elongation at break | ≥35 % | ≥35 % |
| Rockwell B hardness | ≤86 | ≤86 |
Applications
The following are some of the major applications of alloy 926:
- Desalinization systems
- Pulp and paper industry
- Food processing equipment
- Chemical processing plant
- Offshore oil and gas production
- Power generation
