316L Stainless Steel Channel Bar U Shape Stainless Steel Channels in 6m Length
Price:
2400 - 3500 USD/Ton
MOQ:
500 kgs
Delivery Time:
5 - 12 days based on the quantity
Brand:
DELTA
Product Description
316L Stainless Steel Channel Bar U Shape Stainless Steel Channels in 6m Length
| Specifications | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 316 Angle | 5mm to 9mm |
| SS 316 Channel | 40mm*20mm~300mm*300mm |
| SS 316 Beam | 3″ thru 12.31″ |
| SS 316 Chain | 1/8 inch – 1/2 inch Diameter |
| Thickness | 3.0mm – 120mm |
| Length | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
Types of Stainless Steel 316/316L Angle, Channel, Beam, Chain
 |
Stainless Steel 316/316L Angle | SS 316L Architectural Angles 316 SS Equal Leg Angle Stainless Steel 316L Unequal Leg Angle SS UNS S31603 Hot Rolled Steel Angle SS WERKSTOFF NR. 1.4404 Angle Bar ASTM A276 316L Stainless Steel Angle |
 |
Stainless Steel 316/316L Channel | SS 316L C Channel 316 SS C Channel 316L Stainless Steel U Channel SS UNS S31600 U Channel ASTM A276 316 Stainless Steel U Channel |
 |
Stainless Steel 316/316L H Beam | SS 316 H Beam 316L SS H Beam 316 Stainless Steel H Beam SS UNS S31603 H Beam ASTM A479 316L Stainless Steel H Beam |
 |
Stainless Steel 316/316L I Beam | SS 316L I Beam 316 SS I Beam 316L Stainless Steel I Beam SS UNS S31600 I Beam SS WERKSTOFF NR. 1.4401 I Beam ASTM A276 316 Stainless Steel I Beam |
 |
Stainless Steel 316/316L T Beam | SS 316 T Beam 316L SS T Beam 316 Stainless Steel T Beam SS UNS S31603 T Beam SS WERKSTOFF NR. 1.4404 T Beam ASTM A276 316L Stainless Steel T Beam |
 |
Stainless Steel 316/316L Chains | SS 316L Anchor Chain 316 SS Industrial Chain 316L Stainless Steel Lifting Chain SS UNS S31600 NACM Chain SS WERKSTOFF NR. 1.4401 Lifting Chain ASTM A476 316L Stainless Steel Twist Link Chain |
316/316L Stainless Steel Angle, Channel, Beam, Chain Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316 | 0.015 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 16.0-18.0 | 2.0-3.0 | 11.0-14.0 | 67.845 min |
| SS 316L | 0.035 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 16.0-18.0 | 2.0-3.0 | 10.0-14.0 | 68.89 min |
Stainless Steel 316/316L Angle, Channel, Beam, Chain Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Equivalent Grades for 316/316L Stainless Steel Angle, Channel, Beam
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | X5CrNiMo17-12-2 |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | X2CrNiMo17-12-2 |
SS 316/316L Angle, Channel, Beam, Chain Application Industries
- Off-Shore Oil Drilling Companies
- Power Generation
- Petrochemicals
- Gas Processing
- Specialty Chemicals
- Pharmaceuticals
- Pharmaceutical Equipment
- Chemical Equipment
- Sea Water Equipment
- Heat Exchangers
- Condensers
- Pulp and Paper Industry
