Alloy 1.4652 Super Austenitic Stainless Steel Bar Alloy 654SMO Bright Polished Stainless Steel Rod
Alloy 1.4652 Super Austenitic Stainless Steel Bar Alloy 654SMO Bright Polished Stainless Steel Rod
EN 1.4652 stainless steel is a superaustenitic (highly alloyed) stainless steel formulated for primary forming into wrought products. Cited properties are appropriate for the solution annealed (AT) condition. 1.4652 is the EN numeric designation for this material. X1CrNiMoCuN24-22-8 is the EN chemical designation.
It has a fairly high electrical conductivity among wrought superaustenitic stainless steels. In addition, it has the lowest thermal conductivity and a very high tensile strength.
The graph bars on the material properties cards below compare EN 1.4652 stainless steel to: wrought superaustenitic stainless steels (top), all iron alloys (middle), and the entire database (bottom). A full bar means this is the highest value in the relevant set. A half-full bar means it's 50% of the highest, and so on.
More Specification of 654SMO Stainless Steel Bar
| Products | 654SMO/1.4652/UNS S32654 Stainless Steel Bar |
| Diameter | 6 - 300mm |
| Standard | ASTM A276 |
| Length | 6000mm or cutting any length as request |
| Type | Hot rolled/ cold drawn / forged |
| Surface | Black , bright |
| MOQ | 500 kgs |
| Service | cutting , heat treatment (solid solution , aging) |
| Other grade |
201 202 303 303Se 304 304L 309S 310S 316L 316Ti 316LN 316LMod 317L 317LN 321 347 410 420 416 430F 431 440A/B/C 904L 2205 2507 254SMO 654SMO 253MA.etc |
| Loading Port | Shanghai Port |
| Packing | wooden box or as request |
| Deliver time | 5 - 12 days |
Grade & Standard Specification
| Grade : | X1CrNiMoCuN24-22-8 | |||
| Number: | 1.4652 | |||
| Classification: | Austenitic stainless steel - special grade | |||
| Density: | 8 g/cm ³ | |||
| Standard: |
|
Chemical Composition of Alloy 654SMO
| C | Si | Mn | Ni | P | S | Cr | Mo | N | Cu |
| max 0.02 | max 0.5 | 2 - 4 | 21 - 23 | max 0.03 | max 0.005 | 23 - 25 | 7 - 8 | 0.45 - 0.55 | 0.3 - 0.6 |
Standards
- ASTM A276, ASTM A479, ASTM A484, ASTM A484M, DIN 671, DIN 1013, EN 10060, EN 10278, GB1220
Features
- Anti-corrosion (the degree is susceptible to the alloys contained), heat-resistance, good cold and hot working properties, good toughness, good comprehensive performances and wide application.
Applications
- Home appliances, electric appliances, construction materials, medical equipment, auto parts, petroleum, chemical application, agricultural irrigation, edible oil refinery factories, paper plants, shipyard, nuclear power plant etc.
