Product Description
20CrMnMo / 20CrMo5 / 1.7264 Alloy Steel Bar Diameter 10 - 300mm Custom Cutting for Shaft
Products Specification
| Products Name |
20CrMnMo / 20CrMo5 / 1.7264 Alloy Steel Round Bar |
| Diameter | 10 - 320mm |
| Length | 6m or custom cutting any length as request |
| Type | Hot Rolled |
| Brand | BAOSTEEL DELTA DONGBEI HUAXI SHAGANG.etc |
| MOQ | 1 Ton |
| Loading Port | Shanghai Port |
| Packing | packing by steel wire rope |
| Deliver time | 5 - 7 days for stock materials |
| Other Grade |
Q195,Q235,10#,20#,35#,45#,Q215,Q345,12Cr1Mov, 15CrMo,304,316,20Cr,40Cr,20CrMo,35CrMo,42CrMo, 40CrNiMo,GCr15,65Mn,50Mn,50Cr,3Cr2W8V,20CrMnTi,5CrMnMo |
| Standard | ASTM GB EN DIN |
| Application | Structure and Industrial |
Regular Standard Size of our 20CrMo5 Round Bar in Stock
| Standard Diameter | 10 12 15 18 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 120 130 140 150 160 180 200 210 220 230 250 270 300 |
Other Alloy Steel Round Bar We Can Supply:
40CrNiMoA,4340,40CrNi2Mo,34CrNiMo6,17CrNiMo6,20CrNiMoA,8620H,35CrMo,Ⅴ40,20CrMnMo,20MnCr5,30CrNiMo8,18CrNiMo7
Chemical Composition of 1.7264 / 20CrMo5 (in weight %)
| C | Si | Mn | Cr | Mo | Ni | V | W | Others |
| 0.21 | 0.25 | 1.05 | 1.25 | 0.25 | - | - | - | - |
DIN 1.7264 Mechanical
| Yield Rp0.2 (MPa) |
Tensile Rm (MPa) |
Impact KV/Ku (J) |
Elongation A (%) |
Reduction in cross section on fracture Z (%) |
As-Heat-Treated Condition | Brinell hardness (HBW) |
|---|---|---|---|---|---|---|
| 554 (≥) | 349 (≥) | 43 | 23 | 23 | Solution and Aging, Annealing, Ausaging, Q+T,etc | 213 |
Products Range of 20CrMo5 / 1.7264 Alloy Steel
-
Round bar / Wire rod (Diameter): 5.5mm to 800mm
-
Square bar / Flat bar: 3mm to 800mm
-
Length: Fixed length or random length or based on the customer's special requirement.
-
Heavy/middle plate via hot rolled: T6 - 200mm X W1000- 2500mm X L1000-12000mm
-
Sheet steel via cold rolled: T0.5 - 6mm X W600- 1000mm X L1000 - 2000mm
-
Steel strip via cold rolled: T0.1 - 3mm X W5 - 200mm X L (or in coil form)
-
Forging piece: stepped shafts, and other different shapes based on OEM.
Application of 20CrMo5 / 1.7264 Alloy Steel
-
Alloy structural steels are widely used in the filed of ship, vehicle, airplane, guided missile, weapons, railway, bridges, pressure vessel, machine tools, mechanical components with a bigger sectional size and so on.
-
Power generation – turbine fasteners – boiler support rods.
-
Process plant – fasteners, Mechanical gears, gear shaft, main axis, valve rod.
-
Mechanical parts - connecting rod, bolt and nut, Multidiameter shaft, Pressure vessel.
