Abrasion Resistant Steel Plate AR500 Wear Plate / AR500 Plates High Harden Plates
Abrasion Resistant Steel Plate AR500 Wear Plate / AR500 Plates High Harden Plates
Products Specification of Wear Resistant Steel Plate
| Products Name | Abrasion Resistant AR500 Steel Plate |
| Thickness | 4.0 - 40.0mm |
| Width | 100 - 2200mm custom cutting any size as request |
| Length | 6m 8m 10m 11.5m 12m or cutting any length as request |
| Standard | ASTM JIS GB EN |
| MOQ | 500 Kgs |
| Deliver time | 7 - 14 days |
| Loading Port | Shanghai Port |
| Packing | wooden pallets |
| Other Grade | AR400 / AR450 / AR500 / AR600 NM400 NM450 NM500 NM600 |
| Service | Cutting, Heat treatment |
AR500 abrasion resistant steel plate offers high surface hardness for excessive wear and high-impact applications.
A quenched & tempered, through-hardened, abrasion-resistant grade of steel plate. This specialized plate is designed for severe impact and abrasion applications. AR500F exhibits an optimal combination of hardness, abrasion resistance, formability, and weldability. The typical Brinell Hardness range is 470-530.
WHAT IS AR 500 STEEL?
AR500 is a grade of abrasion resistant (AR) steel plate that is known for its hardness, toughness, and resistance to wear and tear. This grade has one of the highest levels of hardness out of the common AR steel plate grades – with a Brinell Hardness Number (BHN) of between 460-544 – and is typically used in high-wear and impact applications.
Overview:
- Abrasion resistant steel plate grade used in high-wear applications, such as in mining equipment and concrete handling.
- Surface hardness can range between 470-540 BNH.
- Possesses excellent resistance to slide wear, rub wear and heavy wear.
- Can withstand high-impact stresses, even at extremely low temperatures.
- Composition and hardening processes differ between mills. Mill test reports are supplied with each order.
Benefits of AR500 Steel
The hardness and toughness of AR500 steel plate make it extremely resistant to wear and impact. These properties make AR500 steel a durable, long-lasting material, which is crucial in applications that require materials that can withstand extreme wear.
The durability of AR500 also means that the material needs to be replaced less often than materials that have lower resistance to abrasion, which can lower material costs and prevent devastating equipment failures.
Mechanical Properties:
- Tensile:
247 ksi TYPICAL – NOT INTENDED FOR STRUCTURAL USE
- Yield:
187 ksi TYPICAL – NOT INTENDED FOR STRUCTURAL USE
- Elongation:
11.1% in 8”
- Brinell:
450 min / 500 nominal
Available Sizes
| THICKNESS | WIDTH | LENGTH | |
|---|---|---|---|
| AR500 | 3/16″ – 2″ | 48″ – 96″ | UP TO 480″ |
