EN 10088 Grade 1.4016 Stainless Steel Strip & Coils Thickness 0.1 - 3.0mm SS Strips
EN 10088 Grade 1.4016 Stainless Steel Strip & Coils Thickness 0.1 - 3.0mm SS Strips
Specification Of Stainless Steel Strip
| Product Name | 430 Stainless Steel Strips |
| Material | Stainless Steel |
| Standard | ASTM JIS GB EN |
| Other Grade | 201 202 301 304 304L 309S 310S 316L 317L 410 420 430 436L 441 2205 2507 904L C276 |
| Thickness | 0.05mm-3.0mm |
| Width | 30mm-600mm |
| Finish | No.1, No.2, Bright Annealed, TR, Polished, etc. |
| Edge | Mill edge, Slit edge, Square edge, Round edge, etc. |
| Coating | PE coating, Paper coating |
| Coil ID | 508mm/610mm |
| Payment Terms | T/T, L/C |
| Delivery Time | As per quantity required |
Type1.4016 / 430 Stainless Steel Strips
Type 430 is a ferritic stainless steel with corrosion resistance approaching that of 304/304L stainless steel. This grade does not work harden rapidly and can be formed using both mild stretch forming, bending, or drawing operations. This grade is used in a variety of interior and exterior cosmetic applications where corrosion resistance is more important than strength. Type 430 has poor weldability compared to most stainless steels due to the higher carbon content and lack of stabilizing elements for this grade, which requires post weld heat treatment to restore the corrosion resistance and ductility. Stabilized grades such as Type 439 and 441
Chemical Composition of EN 1.4016 Stainless Steel
Chemical Composition (wt%) limits as specified in ASTM A240 and ASME SA240*
| Grade | C | Cr | Ni | Mn | Si | P | S | Fe |
| 1.4016 | 0.12 | 16.0-18.0 | 0.75 | 1.00 | 1.00 | 0.040 | 0.030 | Bal |
* Maximum, unless range is indicated
Mechanical Properties of EN 1.4016 Stainless Steel Strip
Mechanical property requirements for annealed product as specified in ASTM A240 and ASME SA240
| Property | 430 |
| Yield Strength, min. (ksi) | 30 |
| Tensile Strength, min. (ksi) | 65 |
| Elongation, min. (%) | 22 |
| Hardness, max. (Rb) | 89 |
| Grade | AISI | EN | UNS | BS | AFNOR | IS | SIS | JIS | UNI |
| SS 430 | 430 | 1.4016 | S43000 | 430 S 17 | Z 8 C 17 | X10 Cr 17 | 142320 | SUS 430 | X12Cr17C |
FAQ
Q:How can I get the price?
Q:Which country have you delivered ?
Q:What is your advantages?
A: We have competitive price,Full of inventory with large warehouse, Complete sizes,grade and MOQ,24 hours online service,feedback within one hour.More important, we have raw material advantages,and the ppgi coil can be supplied with certification and test.
Q:How long is your deliver time?
A:If we have the products on stock, delivery time within 15 days. Otherwise, it will take about 25 days for production and delivery.
Q:How do you ensure my goods?
A:First our clients can visit factory to see the raw material, production lines, warehouse, transportation and inspection
workshop.And you can ask for free sample, we can also process goods as your special requirements. Please do not hesitate to contact us.
Q:How is the goods packaged?
A:The steel coil is packaged with waterproof paper, protective wood black, metal band strapping, inner protective steel ring,outer protective steel ring. Then the coils will be reinforced with wood support in containers, steel lashing belts also used for stable and e.
