EN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 Stainless
Price:
3250 -4500 USD/Ton
MOQ:
500 kgs
Delivery Time:
5 - 12 days based on the quantity
Brand:
DELTA
Product Description
EN 10088 Grade 1.4432 Stainless Steel Plate Thickness 0.4 - 40.0mm X2CrNiMo17-12-3 Stainless Steel
More Informations of our Products
| Item | Stainless Steel Plates / Stainless Steel Sheets |
| Grades | 201, 202, 301, 304, 304L, 310S, 309S, 316, 316L, 321, 409L, 410, 410S, 420, 430, 904L, etc. |
| Thickness | 0.4mm-40mm |
| Stock Thickness | 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2mm, 2.5mm, 3mm, 3.5mm, 4mm, 4.5mm, 5mm, 5.5mm, 6mm, 7mm, 8mm,10mm,12 - 40mm |
| Width | 1000mm 1219mm 1500mm or cutting any size as request |
| Standard size | 1000*2000mm 1219*2438mm 1500*6000mm 2000*6000mm |
| Finish | 2B, BA, No. 1, No. 4, mirror, brush, hairline, chequered, embossed, etc. |
| Package | Standard export package |
Chemical Composition of EN 1.4432 Stainless Steel
| C | Si | Mn | Ni | P | S | Cr | Mo | N |
| max 0.03 | max 1 | max 2 | 10.5 - 13 | max 0.045 | max 0.015 | 16.5 - 18.5 | 2.5 - 3 | max 0.11 |
MECHANICAL PROPERTIES OF GRADE1.4432
| Proof strength Rp0.2(MPa) |
Tensile strength Rm(MPa) |
Impact energy KV(J) |
Elongation at fracture A(%) |
Reduction in cross section on fracture Z(%) |
As-Heat-Treated Condition | Brinell hardness(HBW) |
|---|---|---|---|---|---|---|
| 176(≥) | 215(≥) | 11 | 32 | 43 | Solution and Aging,Annealing,Ausaging,Q+T,etc | 311 |
Equal Grade of 1.4432 Stainless Steel
| EU EN |
USA - |
Japan JIS |
France AFNOR |
England BS |
Sweden SS |
Russia GOST |
| X2CrNiMo17-12-3 | 316L | SUS316L | Z3CND17-13-03 | 316S13 | 2353 | 03KH17N14M3 |
1.4432 RANGE OF PRODUCTS
| Product type | Products | Dimension | Processes | Deliver Status |
|---|---|---|---|---|
| Plates/Sheets | Plates/Sheets | 0.08-200mm(T)*W*L | Forging,hot rolling and cold rolling | Annealed,Solution and Aging,Q+T,ACID-WASHED,Shot Blasting |
| Steel Bar | Round Bar,Flat Bar,Square Bar | Φ8-1200mm*L | Forging,hot rolling and cold rolling,Cast | Black,Rough Turning,Shot Blasting, |
| Coil/Strip | Steel Coil/Steel Strip | 0.03-16.0x1200mm | Cold-Rolled&Hot-Rolled | Annealed,Solution and Aging,Q+T,ACID-WASHED,Shot Blasting |
| Pipes/Tubes | Seamless Pipes/Tubes,Welded Pipes/Tubes | OD:6-219mm x WT:0.5-20.0mm | Hot extrusion,Cold Drawn,Welded | Annealed,Solution and Aging,Q+T,ACID-WASHED |
Product shapes we supply:
- Tool Die Steels in the 1.4432 Special Alloy grade
- Stainless Steels - Special Steels in the 1.4432 Special Alloy grade
- Square and Flat Steel in the 1.4432 Special Alloy grade
- Coil Sheet in the 1.4432 Special Alloy grade
- Bar and Hollow Bar in the 1.4432 Special Alloy grade
- Forgings in the 1.4432 Special Alloy grade
- Superalloy in the 1.4432 Special Alloy grade
- Tube Pipe in the 1.4432 Special Alloy grade
- Non-Magnetic Steel in the 1.4432 Special Alloy grade
- Steels of Blade for Steam Turbine in the 1.4432 Special Alloy grade
