AISI1050 Carbon Steel / Steel Strips 1050 Slit Cutting
AISI1050 Carbon Steel / Steel Strips 1050 Slit Cutting any Width as request
Specification of our products
|
Product Name
|
Cold rolled steel strip
|
|
Thickness
|
0.12-4mm
|
|
Coil Weight
|
3-8 ton, or as your requirement
|
|
width
|
6-700mm, or as your requirement
|
|
Tolerance
|
Thickness: +/-0.02mm, Width:+/-2mm
|
|
Material grade
|
65MN
S50C, C50, CK50, CK50E, SAE 1050 S75C, C75, CK75, CK75E, SAE1075 S60C, C60, CK60, CK60E, SAE1060 S45C, C45, CK45, CK45E, SAE1045 S55C, C55, CK55, CK55E, SAE1055 SK4, SK5, SK85,51CrV4, 75Cr1 60Si2Mn, 55Si2Mn, 62Si2Mn, SUP 6,etc |
|
surface
|
iron gray (low carbon plate), brown (special alloy plate, the high carbon plate), partial ochre (weather resistance), with temperature oxidation pattern, than manufacture rough surface
|
|
Standard
|
ASTM,DIN,JIS,BS,GB/T
|
|
Payment terms
|
30% T/T deposit in advance, 70% T/T balance within 5 days after B/L copy, 100% Irrevocable L/C at sight, 100% Irrevocable L/C
after receive B/L 30-120 days, etc |
|
Delivery times
|
Delivered within 7 days after the receipt of deposit
|
|
Package
|
tied up with steel strips and wrapped with water proof paper
|
|
Application Range
|
Widely used in ship, automobile, Bridges, buildings, machinery, pressure vessels and other manufacturing industries
|
|
Advantages
|
1. Reasonable price with excellent quality
2. Abundant stock and prompt delivery 3. Rich supply and export experience, sincere service |
|
Certificates
|
CE, ISO9001-2008,ETC.
|
AISI 1050 Steel (UNS G10500) in Strip
Description
AISI 1050 is a high-carbon, cold rolled steel containing approximately 0.50% carbon that can be hardened by heat treatment to a maximum hardness of approximately Rockwell C 58. Soft annealed high carbon steel is intended for applications requiring moderate forming, while soft spheroidized annealed product is intended for applications requiring maximum cold forming. The soft spheroidized annealed product is processed to give the lowest hardness for maximum formability. This grade of steel is used for the manufacture of blades, brackets, brake discs, clips, clutches, springs, washers and gears and for a wide range of applications that can make use of its good combination of mechanical properties.
Chemical Composition
Chemical Composition (wt%) limits of AISI 1050*
| Element | AISI 1050 |
| Carbon | 0.48-0.55 |
| Manganese | 0.60-0.90 |
| Phosphorus | 0.030 |
| Sulfur | 0.035 |
Hardness Requirements
Hardness requirements for ASTM A684 annealed high carbon steel (0.55% C)
| Temper | Thickness(inch) | Rockwell HardnessMin.Max. | |
| Under | Through | ||
| Soft Annealed | 0.020 0.030 0.300 |
- 0.020 0.030 |
15T89.5 30T76.0 B88 |
| Soft Spheroidized Annealed | 0.020 0.030 0.300 |
- 0.020 0.030 |
15T88.5 30T74.0 B85 |
Physical Properties of 1050 Steel Strip
Physical properties for AISI 1050 steel
| Property | AISI 1050 Data |
| Density, lb/in3 | 0.284 |
| Modulus of Elasticity, psi | 29 x 106 |
| Coefficient of Thermal Expansion, 68-212˚F, /˚F | 6.39 x 10-6 |
| Thermal Conductivity, Btu/ft hr ˚F | 30.0 |
| Specific Heat, Btu/lb ˚F | 0.116 |
| Electrical Resistivity, Microohm-in | 6.42 |
