UNS S31009 / AISI310H Stainless Steel Plate for Boiler Cold Rolled & Hot Rolled 310H SS Plate
UNS S31009 / AISI310H Stainless Steel Plate for Boiler Cold Rolled & Hot Rolled 310H SS Plate
More Informations of our Products
|
Product
|
Stainless Steel Sheet/Plate
|
|
Standard
|
ASTM A240,GB/T3280-2007,JIS4304-2005,ASTM A167,EN10088-2-2005,etc
|
|
Material
|
310S,310,310H,309,309S,316,316L,316Ti,317,317L,321,321H,347,347H,304,304L,302,301,
201,202,403,405,409,409L,410,410S,420,430,631,904L,Duplex,etc
|
|
Surface
|
2B,2D,BA,NO.1,NO.4,NO.8,8K,mirror,checkered,embossed,hair line,sand blast,Brush
|
|
Thickness
|
Cold Rolled:0.3-6mm
|
|
Hot Rolled: 3-20mm
|
|
|
Width
|
1000mm,1219mm,1500mm,1800mm,2000mm,2500mm,,etc
|
|
Length
|
2000mm,2440mm,3000mm,5800mm,6000mm,etc
|
|
Package
|
Covered with a layer of plastic film and cardboard,packed on the wooden pallets/ iron packing,bound with iron belt,loaded in the containers.
|
|
Price Terms
|
Ex-Work,FOB,CFR,CIF,FCA,etc
|
|
Payment Terms
|
TT,L/C at sight ,western Union,etc.
|
About 310H Stainless Steel Plate
Stainless Steel 310H is the preferred metal of choice for high temperature conditions out of the 310 Stainless Steel grades. It finds use in the heat treatment industry, including the containment of concentrated acids. 310H is often exposed to sulfur dioxide environments and displays a high level of resistance to negative effects, as well as those from oxidation at high temperatures. The metal also displays increased resistance against creep corrosion.
While 310S is the low carbon version of the 310 grades, 310H is the high carbon modification of the metal specifically designed for better resistance to creep, as aforementioned. Its resistance to corrosion in high temperature environments exceeds that of many other stainless steel alloys. However, it does not display the same resistance against aqueous corrosion. In wet environments, its high carbon content works as a limitation.
While the metal can be easily welded and is relatively ductile, cold work practices should be carried out with caution. Extended exposure to cold working can cause carbon precipitation.
Regular Size of 310H Stainless Steel Plate We Have Stock
| 3.0*1500*6000mm | 4.0*1500*6000mm | 5.0*1500*6000mm | 6.0*1500*6000mm |
| 8.0*1500*6000mm | 10.0*1500*6000mm | 12.0*1500*6000mm | 14.0*1500*6000mm |
| 15.0*1500*6000mm | 16.0*1500*6000mm | 18.0*1500*6000mm | 20.0*1500*6000mm |
| 22.0*1500*6000mm | 25.0*1500*6000mm | 30.0*1500*6000mm | 32.0*1500*6000mm |
| 35.0*1500*6000mm | 38.0*1500*6000mm | 40.0*1500*6000mm |
Specifications – Stainless Steel 310 / 310S / 310H
| STANDARD | SS 310 | SS 310S | SS 310H |
|---|---|---|---|
| UNS | S31002 | S31008 | S31009 |
Chemical Composition – 310S / 310H / 310 Stainless Steel
| ELEMENT | 310 | 310S | 310H |
|---|---|---|---|
| NI | 19.0 – 22.0 | 19.0 – 22.0 | 19.0 – 22.0 |
| C | 0.015 max | 0.08 max | 0.04 – 0.10 |
| MN | 2.0 max | 2.0 max | 2.0 max |
| P | 0.020 max | 0.045 max | 0.045 max |
| S | 0.15 max | 0.030 max | 0.030 max |
| SI | 0.15 max | 1.0 max | 1.0 max |
| CR | 24.0 – 26.0 | 24.0 – 26.0 | 24.0 – 26.0 |
| MO | 0.75 max | ||
| N | 0.10 max |
FAQ
Q: How to get samples?
A: The catalog and most samples have been prepared for you. It takes about 5-7 days for customized samples. Please contact us for more support.
Q: What is the minimum order quantity?
A: If you want to order a small number of orders or trial orders, please feel free to contact us, we can meet your requirements.
Q: Can you OEM or ODM?
A: Yes, we have a strong development team. Products can be produced according to your requirements.
Q: How long can you guarantee this product/complete?
A: The color is guaranteed for more than 10 years. The quality certificate of the original materials can be provided.
Q: Which payment method do you accept?
A: We accept payment by wire transfer or letter of credit. In addition, you can also transfer money to our bank account, Western Union or PayPal.
Q: What is the average delivery time?
A: For samples, the delivery time is about 5-7 days. For mass production, the delivery time is 10-25 days. In any case, we will try our best to meet your needs.
Q: Can you provide relevant documents?
