Cold Rolled 316Ti Stainless Steel Sheet 0.6 - 3.0mm 4ft*8ft 5ft*10ft SS Sheets NO.2B Finishing
Cold Rolled 316Ti Stainless Steel Sheet 0.6 - 3.0mm 4ft*8ft 5ft*10ft SS Sheets NO.2B Finishing
Products Specification
|
Product Name
|
316Ti Stainless Steel Sheets
|
|
Material Type
|
Ferrite stainless steel, magnetic; Austenitic stainless steel, Non-magnetic.
|
|
Grade
|
300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347
|
|
200series:201,202,202cu,204
|
|
|
400series:409,409L,410,420,430,431,439,440,441,444
|
|
|
Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc
|
|
|
Duplex stainless steel:S22053,S25073,S22253,S31803,S32205,S32304
|
|
|
Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo
|
|
|
Technology
|
Cold Rolled /Hot Rolled
|
|
Length
|
2000/2438/2500/3000/3048 mm
|
|
Width
|
1000/1219/1250/1500 mm
|
|
Thickness
|
0.4-3mm(cold Rolled), 3-200mm(hot Rolled)
|
|
|
BA, 2B, NO.1,2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed,perforated etc.
|
|
Leveling: improve flatness, esp. for items with high flatness request.
|
|
|
Skin-Pass: improve flatness, higher brightness
|
|
|
Other Choices
|
Cutting:Laser cutting, help the customer to cut the required size
|
|
Protection
|
1. Inter paper available
|
|
2. PVC protecting film available
|
|
|
Price Item
|
FOB,CIF,DDU,FCA,EXW ,.etc
|
|
Quality Assurance
|
1.Provide MTC (Mill Test).
2.Accept the inspection by the third party agent
|
316ti is a titanium stabilized stainless steel. The 316ti Stainless Steel Sheet is designed with a superior chemical concentration of chromium, nickel, and molybdenum. The excellent concentration allows these modules to have enhanced corrosion and oxidation resistance properties. SS 316ti Sheet offers enhanced resistance to pitting by chlorides in seawater.
These high-grade components show higher creep-rupture and stress-rupture properties. A 316ti Stainless Steel Sheet shows resistance to sensitization at temperatures up to 900 degrees F due to the presence of titanium in its composition. Designed with outstanding mechanical properties and strength, the SS 316ti sheet can suffice in a range of stress-induced environments.
Chemical composition of 1.4571
| C | Si | Mn | P | S | Cr | Mo | Ni | Ti |
| ≤ % | ≤ % | ≤ % | ≤ % | ≤ % | % | % | % | ≤ % |
| 0.08 | 1,0 | 2,0 | 0,045 | 0,015 | 16,5-18,5 | 2,0-2,5 | 10,5-13,5 | 5 x C ≤ 0.70 |
Characteristics of 1.4571
| Temperature Range | Density kg/dm3 | Hardness HB |
| Up to 550° C | 8.0 | 30 |
Packing Informations
Stainless steel sheet packaging and loading details:
