UNS S32900 / AISI329 Stainless Steel Round Bar Hot Rolled 329 Stainless Steel Rod OD10 - 250mm
UNS S32900 / AISI329 Stainless Steel Round Bar Hot Rolled 329 Stainless Steel Rod OD10 - 250mm
| Products Name | Stainless Steel Bar | |
| Shape &Size | Round | Dia 6-1200mm |
| Plate/Flat/Block | Thickness 6mm-500mm |
|
| Width 20mm-1000mm |
||
| Heat treatment | Normalized ; Annealed ; Quenched ; Tempered | |
| Surface condition | Black; Peeled; Polished; Machined; Grinded; Turned; Milled | |
| Delivery condition | Forged; Hot rolled; Cold drawn | |
| Test | Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc. | |
| Payment terms | T/T;L/C;/Money gram/ Paypal | |
| Trade terms | FOB; CIF; CNF; EXWetc.. | |
| Delivery time | 5-7 Working days | |
| Application | alloy steels are used for aircraft landing gear, automotive, oil and gas drilling, warm and cold forming, machine building, transfer systems like power transmission gears and shafts, general engineering industries and structural use applicatios such as heavy duty shafts, gears, axles, spindles, couplings, pins, chucks, molds and so on. | |
The Stainless Steel Type 329 is duplex steel being a combination of austenitic and ferritic types. It can resist pitting as well as corrosion cracking under stress. This type of steel is better to use in forged valve pumps and their components.
Type 329 is also frequently used for centrifugal machines. This type of steel forges better at temperatures around 1250/1050C or 2280/1900F. The parts need to be air-cooled once they are forged. Duplex steel of such grade is very difficult to weld, and hence its machinability is very low.
Chemical Properties:
| Elements | Content |
| Iron | 63% |
| Chromium | 28% |
| Nickel | 4.5% |
| Manganese | 2% |
| Molybdenum | 1.5% |
| Silicon | 1% |
| Carbon | 0.10% |
| Phosphorous | 0.040% |
| Sulfur | 0.030% |
Key Features:
- The thermal expansion coefficient (TEC) at 20C to 815C (68F to 1500F) is 14.4µm/mC (8 µin/inF).
- Slightly lower alloy content as compared to Grade 2205.
- Parts and components must be solutions annealed at around 1020C to 1100C (1870F to 2010F) and then must be quenched in water.
Product Forms Available:
- Plates
- Pipes
- Round Bar
- Tube
- Flanges
- Wire
- Fittings
Applications:
- Off-shore technology.
- Paper industry.
- Chemical tanks.
- Heat exchangers.
- Refineries.
- Flanges, fittings, and pipes for the oil and gas industries.
- Compressor parts.
- Marine shafts for pressure vessel parts.
- Desalination plants at seawater.
Other Special Stainless Steel & Nickel Alloy Products
- High temperature alloy: GH3030 GH4169 GH3128 GH145 GH3039 GH3044 GH4099 GH605 GH5188, etc.
- Monel alloy: Monel400 (NO4400)MonelK500 (N05500), etc
- Corrosion resistant alloy: Incone600,601,617,625,686,690,713,718,Inconelx-750, etc
- Inkoloe alloy: Incoloy 20,330,718,800,800H,800HT,825,925,Inconel 926 [N08926/1.4529]
- Hastelloy:Hastelloy C,C-4,C-22( N06022 ),C-276,C-2000,Hastelloy B,B-2,B-3
- Pure nickel / titanium alloy: N4,N5(N02201)N6,N7(NO2200)TA1,TA2,TA9,TA10,TC,etc
- Precipitation hardened steellduplex stainless steel:17-4PH(sus630),17-7PH (sus631), 15-5PH/2205,2507,904L,254SMo,20 # (N08020)
Supply specifications: bar, plate, pipe, strip, capillary, wire and block materials.
