Inconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy Sheets
Price:
40-45 USD/Kg
MOQ:
500 kgs
Delivery Time:
5 - 12 days based on the quantity
Brand:
DELTA
Product Description
Inconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy Sheets
|
Material
|
Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
|
|
Shape
|
Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet
|
|
Grade
|
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
|
|
Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc
|
|
|
Alloy : Alloy 20/28/31
|
|
|
Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g
|
|
|
Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C,
|
|
|
Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602,
|
|
|
Hastelloy C276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665
|
|
|
Haynes: Haynes 230/556/188
|
|
|
Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20
|
|
|
Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851,
|
|
|
Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 /
UNS N06600 / DIN W. Nr. 2.4816 |
|
|
Incoloy: Incoloy 800/800H/800HT/825/925/926;
|
|
|
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
|
|
|
Monel: Monel 400/K500/R405
|
|
|
Nitronic: Nitronic 40/50/60;
|
|
|
Nimonic: Nimonic 75/80A/90/A263 ;
|
|
|
Specification
|
Wire: 0.01-10mm
|
|
Strip: 0.05*5.0-5.0*250mm
|
|
|
Bar: φ4-50mm;Length 2000-5000mm
|
|
|
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
|
|
|
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
|
Inconel 625 Sheet & Plate - UNS N06625
High strength and corrosion resistant, Inconel 625® is a nonmagnetic, nickel-based alloy with a very broad operational temperature range (cryogenic to 2,000°F/1,093°C). Inconel 625® is known for its toughness, high fatigue strength, and oxidation resistance.
Inconel 625 Sheet & Plate for All Applications
Magellan Metals offers Inconel 625 sheet in a range of standard thicknesses from 0.010” to 0.156”. Our Inconel 625 plate is available in thicknesses up to 4”. All our Inconel 625 sheet and plate meets a variety of national and international specifications, including:- ASTM B443
- AMS 5599
- AMS 5869
- ISO 6208
- and others (see table below)
Nominal Composition
| C | Mn | Si | P | S | Cr | Mo | Nb | Co | Ti | Al | Fe | Ni | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | – | – | – | – | – | 20.00 | 8.00 | 3.15 | – | – | – | – | – |
| MAX | 0.10 | 0.50 | 0.50 | 0.015 | 0.015 | 23.00 | 10.00 | 4.15 | 1.00 | 0.40 | 0.40 | 5.00 | BAL |
Typical Mechanical Properties
| Condition | Heat Treatment | Tensile Strength | Suggested Operating Conditions |
|---|---|---|---|
| Annealed | 1925-2050oF (1050-1120°C) | 120 – 150 ksi (830-1100 MPa) | -300°F to 1800°F (-184°C to 980°C) |
| Spring Temper | – | 200 – 250 ksi (1380 – 1724 MPa) | -300°F to 700°F (-184°C to 370°C) |
We also offer Inconel 625 wire, bar, tube, pipe, fittings, flanges, forgings, and welding rod.
| Product Form | Size range from | Size range to |
|---|---|---|
| Alloy 625 pipe | 0.5 in | 8 in |
| Alloy 625 coil | 0.25 mm | 3.18 mm |
| Alloy 625 welding wire | 0.5 mm | 3.175 mm |
| Alloy 625 sheet & plate | 0.25 mm | 76.2 mm |
| Alloy 625 round bar | 12 mm | 260 mm |
| Alloy 625 pipe fittings | 0.5 in | 8 in |
| Alloy 625 flanges | 0.5 in | 8 in |
Applications include:
- Honeycomb
- Springs
- Seals
- Bellows
- Diaphragms
- Land-based turbine components
- Aircraft exhaust
ducting - Heat exchangers
Industries supplied include:
- Automotive
- Marine
- Chemical Processing
- Power Generation
- Nuclear
- Aerospace
