EN 10204-3.1 Materical Certificate Hastelloy C276 Pipe Tube / Seamless Pipe Welded Tube
EN 10204-3.1 Materical Certificate Hastelloy C276 Pipe Tube / Seamless Pipe Welded Tube
Product Details:
| Product Name: | Hastelloy c276 pipe | |
| Material: | Hastelloy c276 UNS N09901 ; DIN W.Nr.2.4819 | |
| Specification: | Wire: 0.01-10mm Strip: 0.05*5.0-5.0*250mm Bar: φ4-50mm;Length 2000-5000mm Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm |
|
| Standard: | GB,AISI,ASTM,DIN,EN,SUS,UNS etc | |
| Inspection: | ISO, SGS, BV, and so on. | |
| Product Characteristics: |
1. According to the preparation process can be divided into deformation superalloys, casting superalloys and powder metallurgy superalloys. 2. According to the strengthening mode, there are solid solution strengthening type, precipitation strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc.. |
|
| Application: | High-temperature components such as turbine blades, guide vanes, turbine disks, high pressure compressor disks, machine manufacturing and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines |
|
| Delivery: | 7-25days or according to the product | |
| Payment: | L/C,D/A,D/P,T/T,Western Union,MoneyGram,According to customer requirements payments for offline orders. | |
Hastelloy C276 is a high performance super alloy grade. A Hastelloy C276 Pipe is designed possessing an outstanding content of nickel, chromium, and molybdenum with other constituting alloys. The superior content gives these pipes enhanced corrosion and oxidation resistance properties. The Hastelloy C276 Tube can operate in standard temperatures of 1900 degrees F while showing superior resistance to crevice corrosion and pitting by acidic media in reducing environments. The low carbon content allows the C276 Tubing to be easily welded in place using standard procedures. The tubing has a minimum tensile strength of 690mpa with a minimum yield strength of 283mpa and can be readily elongated by 40%. The versatile grade is a common feature in chemical processing, marine engineering, pharmaceutical system, sour service system, pulp and paper productions, pollution control, etc.
The Hastelloy C276 Seamless Pipe is a high-strength piping grade in this range. Here the pipes are produced by passing hot steel billets through the extruded to shape it in precise dimensions. The pipes have enhanced load-bearing capacity compared to other pipe types in this grade. Hastelloy Pipe can be treated following different procedures. To meet customer satisfaction these pipes can be custom designed, grooved as per different project requirements. We are the leading Hastelloy C276 Pipe Manufacturers in the country. We believe in quality over anything and believe in creating long-term relationships with our esteemed customers.
Hastelloy C276 Pipe Specification
| Specifications | ASTM B 622 / ASTM B 619, ASME SB 622 / SB 619 |
|---|---|
| Form | Hydraulic, Round, Square, etc |
| Dimensions | ASME, API and ASTM |
| Type of Hastelloy C276 Pipe | Welded / ERW / Seamless / Fabricated |
| Size | From 15″NB to 150″NB |
| Length | Double Random, Cut Length adn Single Random |
| Specialized in | Large Diameter Size |
| End | Beveled End, Plain End, Treaded |
| Schedule of Hastelloy C276 Tube | Schedule 5 to 160 |
We stock and produce Hastelloy C276 Tubes in various shapes, check DIN 17751 exhaust tubing Chemical and Mechanical Properties
Hastelloy C276 Welded Pipe Chemical Composition
| Hastelloy C276 | Fe | Ni | P | C | S | Mo | Co | Mn | Cr | Si |
|---|---|---|---|---|---|---|---|---|---|---|
| 4.00 – 7.00 | Balance | 0.04 max | 0.010 max | 0.03 max | 15.00 – 17.00 | 2.5 max | 1.00 max | 14.50 – 16.50 | 0.08 max |
ASTM B622 Hastelloy C276 Tube Mechanical Properties
| Density | Tensile Properties | Melting Point | Elongational | Yield Properties (0.2%Offset) |
|---|---|---|---|---|
| 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 1370 °C (2500 °F) | 40 % | Psi – 52,000 , MPa – 355 |
Alloy C276 Seamless Pipe Equivalent
| STANDARD | EN | UNS | BS | WERKSTOFF NR. | JIS | AFNOR | GOST |
|---|---|---|---|---|---|---|---|
| Hastelloy C276 | NiMo16Cr15W | N10276 | – | 2.4819 | NW 0276 | – | ХН65МВУ |
C276 Alloy Pipe Test
- Positive Material Identification – PMI Testing
- Micro and MacroTest
- Chemical Analysis – Spectro Analysis
- Hardness Test
- Flaring Test
- Intergranular Corrosion Test
- Pitting Resistance Test
- Flattening Test
- Mechanical Testing
