Inconel 600 Plate Alloy 600 Sheets Cold Rolled & Hot Rolled 1000mm 1219mm 1500mm Width
Inconel 600 Plate Alloy 600 Sheets Cold Rolled & Hot Rolled 1000mm 1219mm 1500mm Width
| Material | Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy |
| Shape | Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet |
|
Grade |
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L |
| Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc | |
| Alloy : Alloy 20/28/31 | |
| Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g | |
| Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C, Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602, Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665 |
|
| Haynes: Haynes 230/556/188 | |
| Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20 | |
| Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851, Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 / UNS N06600 / DIN W. Nr. 2.4816 |
|
| Incoloy: Incoloy 800/800H/800HT/825/925/926; | |
| GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044 | |
| Monel: Monel 400/K500/R405 | |
| Nitronic: Nitronic 40/50/60; | |
| Nimonic: Nimonic 75/80A/90/A263 ; | |
|
Specification |
Wire: 0.01-10mm Strip: 0.05*5.0-5.0*250mm Bar: φ4-50mm;Length 2000-5000mm Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm |
| Product Characteristics |
1.According to the preparation process can be divided into deformation superalloys, casting superalloys and powder metallurgy superalloys. 2.According to the strengthening mode, there are solid solution strengthening type, precipitation strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc.. |
| Standard | GB,AISI,ASTM,DIN,EN,SUS,UNS etc |
| Inspection | ISO,SGS,BV,PMI and so on. |
ASME SB-168 Inconel 600 Sheet & Plate
Inconel 600 alloys are oxidation and corrosion resistant materials well suited for service in extreme environments subjected to pressure and heat.
Specifications
| Grade | UNS | Standards | |
| Inconel 600 | UNS N06600 | ASME SB-168 | AMS 5540 |
Hitech Alloy specializes in manufacturing, supplying and exporting Inconel 600 sheets, plates, coils and cut-to-length size for plates.
Inconel alloys are oxidation and corrosion resistant materials well suited for service in extreme environments subjected to pressure and heat. Inconel alloys are typically used in industries having high temperature applications.
Chemical Compositon
| Item | Inconel 600 | Inconel 601 | |
| Chemical Composition (%) | C | ≤0.15 | ≤0.1 |
| Mn | ≤1.0 | ≤1.0 | |
| Si | ≤0.5 | ≤0.5 | |
| S | ≤0.015 | ≤0.015 | |
| Cr | 14.0~17.0 | 21.0~25.0 | |
| Ni | ≥72 | 58.0~63.0 | |
| Fe | 6.0~10.0 | bal | |
| Al | ≤0.5 | ||
| Cu | ≤0.5 | ≤0.5 | |
Our Inconel 600 Products
● Inconel 600 sheets
● Inconel 600 plates
● Inconel 600 coils
● ASME SB-168 Inconel 600 sheets
● AMS 5540 Inconel 600 sheets
● ASME SB-168 Inconel 600 plates
● AMS 5540 Inconel 600 plates
● ASME SB-168 Inconel 600 coils
● AMS 5540 Inconel 600 coils
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
