High Carbon 316 Stainless Steel Plates Laser Cutting Thickness 3.0 - 80.0mm SA240
High Carbon 316 Stainless Steel Plates Laser Cutting Thickness 3.0 - 80.0mm SA240
|
Material
|
200 300 400 Series stainless steel
|
|
Grade
|
201 202 301 303 304 304L 2205 2507 309 309S 310 310S 314 316L 316Ti 317L 321 2205 2507 409 409l 410 410S 420 420J1 420J2 430 441 444 904L
|
|
Standard
|
AISI ASTM JIS DIN EN BS
|
|
Tech
|
Cold rolled / Hot rolled
|
|
Thickness
|
Hot rolled: 3mm-16mm 16-150mm
Normal: 3.0 4.0 5.0 6.0 8.0 10.0 12.0 14.0 16.0
As per customer's request: 16-150mm Cold rolled: 0.3-6mm
Normal:0.3/0.4/0.5/0.6/0.7/0.8/0.9/1.0/1.2/1.5/2.0/2.5/3.0 As per customer's request: 4.0/5.0/6.0 |
|
Width&Length
|
1000mm-6000mm, or as per customer's request
Hot rolled: 1250*3000mm (4.1*10ft) 1500*3000mm (5*10ft) 1250*6000mm (4.1*19.6ft) 1500*6000mm (5*19.6ft) 1800*6000mm (5.9*19.6ft) 2000*6000mm(6.5*19.6ft) Cold rolled: 1000*2000mm (3.2*6.5ft) 1219*2438mm (4*8ft) 1500*3000mm (5*10ft) 1800 available 2000 available |
|
Place of Origin
|
Jiangsu China
|
|
Processing Service
|
Bending, Welding, Recoiling, Punching, Cutting
|
|
Tolerance
|
±1%
|
|
Surface Treatment
|
N0.1,2B,BA,6K, 8K, 12k, N0.4, HL, Mirrored,checkered etc
|
|
Payment
|
T/T terms, 30% pre-payment, 70% balance see B/L copy LC Western Union Paypal
|
|
Delivery Time
|
5-15 days for ordinary orders (standard orders <=50 ton); specified orders needs final confirmation as per customer's request
|
Resists Corrosion
316 stainless steel plate is excellent for harsh environment applications, including marine, chemical and industrial. High-quality 316 stainless steel plate from TCI Precision Metals is designed to hold up. TCI Precision Metals is a value-added stainless steel distributor; we source mill-direct and process materials to your exact specifications, delivering Machine-Ready Blanks that are ready to go from receiving directly into your machining centers.
316 stainless steel plate is an austenitic alloy with increased nickel and molybdenum content that demonstrates superior corrosion-resistant properties. It provides excellent high temperature tensile, creep and stress-rupture strength, as well as outstanding formability and weldability. This material type has lower carbon content than other alloys, making it very popular for heavy-gauge welded applications.
| pplications for 316 Plate | Specifications |
|---|---|
| Marine applications | Standard thickness ranges from .190 to 1.000 inches |
| Industrial equipment | Non-standard thicknesses up to 6.000 inches |
| Exposure to corrosive chemicals | |
| High chloride exposure | |
| Laboratory instruments | |
| Rubber and plastic manufacturing processes | |
| Pharmaceutical | |
| Heat exchangers | |
| Coastal area structures | |
| Liquid processing equipment | |
| Condensers, evaporators, and tanks | |
| Food processing equipment | |
| Architectural | |
| Aerospace parts |
| Chemical Composition Limits (WT%) | Mechanical Properties | ||
|---|---|---|---|
| Carbon | 0.08 max | Yield Strength 0.2% Offset Psi (MPa) |
30,000 205 |
| Manganese | 2.00 max | Ultimate Tensile Strength Psi (MPa) |
75,000 515 |
| Silicon | 0.75 max | Percent Elongation in 2 in. or 51mm | 40 |
| Chromium | 16.00 – 18.00 | Hardness, Max. Brinell |
217 95 |
| Nickel | 10.00 – 14.00 | ||
| Molybdenum | 2.00 – 3.00 | ||
| Phosphorus | 0.045 max | ||
| Sulfur | 0.030 max | ||
| Nitrogen | 0.10 max | ||
| Iron | Bal. | ||
