317L Stainless Steel Plate - UNS S31703 / 1.4438 SS Plates Width 1000mm 1250mm 1500mm 2000mm
Price:
2400 -3220 USD/Ton
MOQ:
400 kgs
Delivery Time:
5 - 12 days based on the quantity
Brand:
DELTA
Product Description
317L Stainless Steel Plate - UNS S31703 / 1.4438 SS Plates Width 1000mm 1250mm 1500mm 2000mm
|
Material
|
200 300 400 Series stainless steel
|
|
Grade
|
201 202 301 303 304 304L 2205 2507 309 309S 310 310S 314 316L 316Ti 317L 321 2205 2507 409 409l 410 410S 420 420J1 420J2 430 441 444 904L
|
|
Standard
|
AISI ASTM JIS DIN EN BS
|
|
Tech
|
Cold rolled / Hot rolled
|
|
Thickness
|
Hot rolled: 3mm-16mm 16-150mm
Normal: 3.0 4.0 5.0 6.0 8.0 10.0 12.0 14.0 16.0
As per customer's request: 16-150mm Cold rolled: 0.3-6mm
Normal:0.3/0.4/0.5/0.6/0.7/0.8/0.9/1.0/1.2/1.5/2.0/2.5/3.0 As per customer's request: 4.0/5.0/6.0 |
|
Width&Length
|
1000mm-6000mm, or as per customer's request
Hot rolled: 1250*3000mm (4.1*10ft) 1500*3000mm (5*10ft) 1250*6000mm (4.1*19.6ft) 1500*6000mm (5*19.6ft) 1800*6000mm (5.9*19.6ft) 2000*6000mm(6.5*19.6ft) Cold rolled: 1000*2000mm (3.2*6.5ft) 1219*2438mm (4*8ft) 1500*3000mm (5*10ft) 1800 available 2000 available |
|
Place of Origin
|
Jiangsu China
|
|
Processing Service
|
Bending, Welding, Recoiling, Punching, Cutting
|
|
Tolerance
|
±1%
|
|
Surface Treatment
|
N0.1,2B,BA,6K, 8K, 12k, N0.4, HL, Mirrored,checkered etc
|
|
Payment
|
T/T terms, 30% pre-payment, 70% balance see B/L copy LC Western Union Paypal
|
|
Delivery Time
|
5-15 days for ordinary orders (standard orders <=50 ton); specified orders needs final confirmation as per customer's request
|
Designed as per international and national standards, these UNS S31700, S31703 Sheet & Plate are offered in customized length sizes and shapes to our esteemed clients. Also referred as WNR 1.4449, 1.4438 Sheet & Plate these are available at best possible rates in the market.
We are an authorized Dealer, as well as Supplier of Stainless Steel 317 / 317L Sheet & Plate of various Approved Manufacturing companies like Jindal Steel Works, Acreinox, Columbus Stainless, Outokumpu, Thyssenkrupp etc.
SS 317 / 317L SHEETS AND PLATES SPECIFICATIONS :
| Dimensions | 317L Stainless Steel Plate |
|---|---|
| Standard | ASTM A240 / ASME SA240 |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm |
| Thickness | 4mm-40mm |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Surface Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc |
EQUIVALENT GRADES FOR STAINLESS STEEL 317 / 317L SHEET & PLATE
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 317 | 1.4449 | S31700 | SUS 317 | – |
| SS 317L | 1.4438 | S31703 | SUS 317L | X2CrNiMo18-15-4 |
CHEMICAL COMPOSITION OF SS 317 / 317L SHEETS & PLATES
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18 – 20 | 3 – 4 | 11 – 15 | 57.845 min |
| SS 317L | 0.035 max | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 18 – 20 | 3 – 4 | 11 – 15 | 57.89 min |
MECHANICAL PROPERTIES FOR SS 317 / 317L SHEETS & PLATES
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
TYPES OF SS 317 / 317L SHEET & PLATE
- Stainless Steel 317 Cold Rolled Sheets Supplier
- 317L Stainless Steel Sheets and Plates Dealer
- SS 317 Round Sheet Exporter
- 317L Stainless Steel Cold Rolled Plates
- ASME SA240 SS Sheet Stockist
- Stainless Steel SA240 TP317L Embossed Plates
- UNS S31703 Cold Rolled Plates
- 1.4438 SS Sheets Manufacturer
- AISI 317 Steel Sheets / Plates
- TP 317L SS Embossed Sheets Manufacturer in India
- Stainless Steel 317 Hot Rolled Plates
- ASTM A240 TP317 Cold Rolled Sheet Supplier in Saudi Arabia
- UNS S31700 SS Finish Plates Stockist in Riyadh
- ASTM A240 TP317 Finish Stainless Sheet
- 317 Austenitic Stainless Steel 2D Finish Sheets
- Stainless Steel 317 Sheet / Plates / Coils Exporter
- SS 317L Plates Dealer
- 317 Stainless Steel Plates Stockholder
