SCH40S SCH80S TP316L Stainless Steel Hollow Pipe DN10 - DN800 TP316 / TP316L
SCH40S SCH80S TP316L Stainless Steel Hollow Pipe DN10 - DN800 TP316 / TP316L
| Product Name | Stainless Steel Pipe Ss Pipe |
| Fabrication Standard | ASTM A213/269/312/789 |
| Material Grade | TP304 TP316 TP310S SS32750 TP321 TP347L 2507 S32205 254SMo 904L.etc |
| Out Diameter | 1/8" - 24" |
| Wall Thickness | 1.25mm - 80mm |
| Length | <= 18 Mtr |
| Surface | anealling and pickles surface, polishing |
| Package | by piece, in bundles, with external pvc wrapped, wood crated |
| Minimum Order Quantiy | 1 Metric Tons |
| Our Advantage | 1.regular sizes in stock over 2000 tons for immediate delivery |
| 2.small quantity with factory rate | |
| 3.quality certificate as per EN10204 3.1b issued by manufacturer | |
| 4.expert technical and export/import document consultant and support | |
| 5.on-time response by email, skype, website and online messages |
Products Description
Stainless steel seamless pipe is a long strip of steel with a hollow section and no seams around it. The thicker the wall thickness of the product, the more economical and practical it is, and the thinner the wall thickness, the higher its processing cost will be.
The process of this product determines its limited performance. Generally, seamless steel pipes have low precision, uneven wall thickness, low brightness inside and outside the tube, high cost of cutting to length, and pits and black spots on the inside and outside are not easy to remove. Its detection and Shaping must be handled offline. Therefore, it embodies its superiority in terms of high pressure, high strength, and mechanical structural materials.
Product Parameters
| Product Name | ASTM A312 TP316L Stainless Steel Pipe |
| Out Diameter | 19-813mm |
| Wall Thickness | 0.5-60mm |
| Material Standard | ASTM A312 |
| Steel Grade | ASTM A312 TP316L |
| Surface | Pickling, Solid solution, Polishing |
| Packing | Plastic Film, Plastic Cap, Bundle, Woven bag, Wooden Case, Iron Frame |
| Delivery | Within 3 days with stock, 15-50 days based on production |
| Payment | T/T, D/P, L/C at sight, Usance L/C etc. |
Chemical Requirements
| Grade | C | Mn | P | S | Si | Cr | Ni |
| TP316L | 0.035max | 2.00max | 0.045max | 0.030max | 1.00max | 16.00-18.00 | 10.00-14.00 |
Mechanical Property
| Grade |
Tensile strength Min Ksi(Mpa) |
Yield strength Min Ksi(Mpa) |
Elongation % min |
| TP316L | 70(485) | 25(170) | 35 |
