Width 2200mm 2000mm Alloy Steel Plate 42CrMo4 ASTM EN DIN GB Standard
Width 2200mm 2000mm Alloy Steel Plate 42CrMo4 ASTM EN DIN GB Standard
Products Specification of Steel Plate
| Products Name | 42CrMo4 Alloy Steel Plate |
| Thickness | 10.0 - 200.0mm |
| Width | 100 - 2200mm custom cutting any size as request |
| Length | 6m 8m 10m 11.5m 12m or cutting any length as request |
| Standard | ASTM JIS GB EN |
| MOQ | 500 Kgs |
| Deliver time | 7 - 14 days |
| Loading Port | Shanghai Port |
| Packing | wooden pallets |
| Other Grade | AR400 / AR450 / AR500 / AR600 NM400 NM450 NM500 NM600 |
| Service | Cutting, Heat treatment |
42CrMo steel is a Chinese alloy steel, and has high strength and toughness, good hardenability, and no obvious temper brittleness. After quenching and tempering treatment, it has high fatigue limit and resistance to multiple impacts, and good low temperature impact toughness.
Applications
42CrMo alloy steel generally used for engineering steel purpose, and for making important parts requiring higher strength and larger size of the quenched section than 35CrMo steel, such as shafts, crankshafts, large gears for locomotive traction, supercharger gears, gearbox gears, engine cylinders, oil drill pipe joints, large load rods and spring clips.
42CrMo Steel Chemical Composition
| Chemical Composition % | |||||||
| Steel Grade | C | Si | Mn | P | S | Cr | Mo |
| 42CrMo | 0.38 to 0.45 | 0.17 to 0.37 | 0.50 to 0.80 | ≤ 0.030 | ≤ 0.030 | 0.90 to 1.20 | 0.15 to 0.25 |
42CrMo Alloy Steel Mechanical Properties
- Yield strength: ≥ 930 MPa
- Tensile strength: ≥ 1080 MPa
- Elongation: ≥12%
- Rate of reduction in area: ≥45%
- Impact absorbing energy: ≥ 63 J
- Material Brinell hardness: ≤229 (Annealed or high temperature tempered steel rod)
- Sample diameter: 25mm
Heat treatment specification
- First quenching heating temperature: 850 °C (Cooling – oil)
- Tempering heating temperature: 560 °C (Cooling – water, oil)
Equivalent
42CrMo steel equivalent to US AISI ASTM, European EN (Germany DIN EN, UK BSI EN, France NF EN, Japan JIS, and ISO standard.
| China | USA | Germany | UK | Japan | France | ISO | ||||||
| Standard | Grade | Standard | Grade | Standard | Grade (Steel number) | Standard | Grade (Steel number) | Standard | Grade | Standard | Grade (Steel number) | Standard |
| GB/T 3077 | 42CrMo | SAE, AISI; ASTM A29/A29M |
AISI 4140 steel | DIN EN 10083-3 | 42CrMo4 (1.7225) | BS EN 10083-3 | 42CrMo4 (1.7225) | JIS G4105 | SCM440 | NF EN10083-3 | 42CrMo4 (1.7225) | ISO 683-17 |
