ASTM A312 TP310 Seamless Pipe Characteristics
- Tensile And Fractal Properties At Cryogenic Temperatures
- Moderate Strength In A Hot Environment
- A Defence Against Heat Corrosion
- Resistance To Oxidation Up To 2000 °f
Stainless Steel 310 Pipes Chemical Composition
| Grade | Sulphur | Carbon | Silicon | Manganese | Phosphorous | Chromium | Nickel | |
|---|---|---|---|---|---|---|---|---|
| Stainless Steel 310 Pipe | Minimum | 24.0 | 19.0 | |||||
| Maximum | 0.030 | 0.25 | 1.50 | 2.0 | 0.045 | 26.0 | 22.0 | |
Mechanical Properties of ASTM A312 TP310 ERW pipes
Exporter & supplier of 310S Stainless Steel Pipe and 310 Seamless Pipe as per ASTM/ ASME A213, EN, IBR, UNI
| Grade | Elongation | Yield Strength | Tensile Strength Minimum | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) Maximum | Brinell (HB) Maximum | ||||
| SS 310 Pipe | 40% | 205 | 515 | 95 | 217 |
310S Stainless Steel Pipes Equivalent
| Grade | Unified Numbering System | Euronorm | Japanese JIS | |
|---|---|---|---|---|
| No | Name | |||
| 310 Stainless Steel pipe | S31000/S31008 | 1.4841/1.4845 | SUS 310 310S | |
SS 310 Seamless Pipes Creep Properties
Stockist of SS 310S Tube in Wall thickness from 0.020″ to 0.250″ in form of round & square
| Rupture2) for | 1% Elongation1) for | ||||
|---|---|---|---|---|---|
| 10,000 h N/mm2 | 1,000 h N/mm2 | 10,000 h N/mm2 | 100,000 h N/mm2 | Temperature °C | 1,000 h N/mm2 |
| 30 | 80 | 40 | 18 | 700 | 45 |
| 4 | 15 | 8.5 | 3 | 900 | 10 |
| 90 | 170 | 130 | 80 | 600 | 100 |
| 10 | 35 | 18 | 7 | 800 | 18 |
310 Stainless Steel Pipes Application
- Kilns
- Steam boilers and thermowells
- Engineering industry
- Radiant Tubes
- Cement industry
- Heat treatment baskets
- Energy conversion plants
- Food processing equipment
- Cryogenic structures
- Oil industry equipment
- Heat Exchangers
- Saggers
