Stainless Steel 310 tubing composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 310 | min. | – | – | – | – | 24.0 | 0.10 | 19.0 | – | |
| max. | 0.015 | 2.0 | 0.15 | 0.020 | 0.015 | 26.0 | 21.0 | – | ||
| 310S | min. | – | – | – | – | – | 24.0 | 0.75 | 19.0 | – |
| max. | 0.08 | 2.0 | 1.00 | 0.045 | 0.030 | 26.0 | 22.0 | – | ||
Stainless Steel 310 Tube mechanical properties
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 310 | 515 | 205 | 40 | 95 | 217 |
| 310S | 515 | 205 | 40 | 95 | 217 |
Equivalent Grades for Stainless Steel 310 Tube
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | GOST | ||
|---|---|---|---|---|---|---|---|---|
| BS | En | No | Name | |||||
| 310 | S31000 | 304S31 | 58E | 1.4841 | X5CrNi18-10 | 2332 | SUS 310 | 20Ch25N20S2 |
| 310S | S31008 | 304S31 | 58E | 1.4845 | X5CrNi18-10 | 2332 | SUS 310S | 20Ch23N18 |
ASTM A269 SS 310 310S coiled tubing
310 Stainless Steel straight tube heat exchanger
SS UNS S31008 straight tube boiler
Stainless Steel 310S Tubing
Alloy 310 310S extreme environment gas tube
Stainless Steel 310 tube stock
GOST 20Ch23N18 welded tubing
SS 310S tubing bends
SS UNS S31000 thin wall tubing
ASTM A249 TP 310S Stainless Steel tube
ASTM A213 Stainless Steel mechanical tubing
310 Stainless Steel Capillary Tubing
Stainless Steel 310/310S Heat Exchanger Tube
ASTM A213 Gr. TP310/310S seamless tube
Applications
With its high heat resistance characteristics typical applications include parts for furnaces, heat treatment baskets, jigs, case hardening boxes, steam locomotives parts, burners, combustion chambers, heat exchangers and food processing equipment.
