Hastelloy B-2 Strip Rolls Thickness 0.1 - 3.0mm UNS N10665 Alloy B2 Coils
Hastelloy B-2 Strip Rolls Thickness 0.1 - 3.0mm UNS N10665 Alloy B2 Coils
| Item | Hastelloy B2 Strips |
|---|---|
| Grade |
200 series: 201, 202, etc. 300 series: 301, 304, 304L, 316L, 321, 316Ti, etc. 400 series: 409L, 410, 410L, 420, 430, 434,439, etc. Duplex series: S31803, S32750, S32550, etc. Super Authentic: 904L, 254SMO, etc. Precipitation Hardening: 17-4PH, 17-7PH, etc. Nickel alloy: c276 B2 400 600 625 800 825 916.etc |
| Hardness |
Soft O, 1/4H, 1/2H, H |
| Thickness |
0.3 - 120 mm |
| Width |
≤ 600 mm |
| Length |
Coil |
| Surface |
2B, No.1, No.3, NO.4, HL |
About Hastelloy B2
Hastelloy B2 is a nickel-molybdenum alloy with significant resistance to reducing environments, such as hydrogen chloride gas and sulfuric, acetic and phosphoric acids. Hastelloy B2 provides resistance to pure sulfuric acid and a number of non-oxidizing acids. The alloy should not be used in oxidizing media or where oxidizing contaminants are available in reducing media. Premature failure may occur if alloy B2 is used where iron or copper is present in a system containing hydrochloric acid.
Industry users like the resistance to a wide range of organic acids and the resistance to chloride-induced stress-corrosion cracking.
Hastelloy B2 resists the formation of grain boundary carbide precipitates in the weld heat-affected zone, making it suitable for most chemical process applications in the as-welded condition. The heat-affected weld zones have reduced precipitation of carbides and other phases to ensure uniform corrosion resistance.
Alloy B2 also has excellent resistance to pitting and stress corrosion cracking.
Chemical Composition of Hastelloy B2
|
|
Ni |
Mo |
Fe |
Cr |
C |
Si |
Mn |
|---|---|---|---|---|---|---|---|
|
Max |
Bal. |
30.0 |
2.0 |
1.0 |
0.02 |
0.10 |
1.0 |
|
Min |
|
26.0 |
|
|
|
|
|
Mechanical Property of Hastelloy B2
|
|
Ultimate Tensile |
Yield Strength (0.2% OS) |
Elong. % |
R/A |
Hardness Rockwell
|
|---|---|---|---|---|---|
| Min | 110 Ksi | 51 KSi | 40 | ||
| Max | |||||
| Min | 760 MPa | 350 MPa | |||
| Max |
Application of Hastelloy B2
Superior resistance to hydrochloric acid, aluminum chloride catalysts and other strongly reducing chemicals. Excellent high-temperature strength in inert and vacuum atmospheres.
Hastelloy B2 is a nickel-molybdenum alloy particularly suited for equipment handling reducing chemical environments .
Applications in the chemical process industry involving sulfuric, phosphoric, hydrochloric and acetic acid. Temperature uses vary from ambient temperature to 1500°F depending on the environments (please call for technical advice).
